Retry Settings; Host Information; Channel 1 And Channel 2 Configuration; Figure 5-5. Hostlist Settings - Lantronix Micro125 User Manual

2. Enter or modify the following fields:

Retry Settings

Retry Settings
Retry Counter
Retry Timeout

Host Information

Host Information
Settings
Host Address
Port
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.

Channel 1 and Channel 2 Configuration

The Channel 1 and Channel 2 configuration defines how the serial port responds to network
and serial communication.
Micro125 User Guide

Figure 5-5. Hostlist Settings

Description
Enter the value for the number of times the Micro125 should attempt to
retry connecting to the host list.
Enter the duration (in milliseconds) the Micro125 should abandon
attempting a connection to the host list.
Description
Enter or modify the host's IP address.
Enter the target port number.
5: Configuration Using Web Manager
25
