SPECIFICATIONS AND OPTIONS

■ Specifications

IC-M510BB USA Version
D General
• Frequency coverage:
• Mode:
• Operating temperature range:
• Current drain (at 13.8 V):
• Power supply requirement:
• Antenna impedance:
• Dimensions:
• Weight (approximate):
D Transmitter
• Output power:
• Modulation system:
• Maximum frequency deviation: ±5 kHz
• Spurious emissions:
• Frequency tolerance
• Adjacent channel power:
• Audio harmonic distortion:
• Residual modulation:
• Audio frequency response:
D Receiver
• Receive system:
• Sensitivity:
• Squelch sensitivity:
• Intermodulation rejection ratio:
• Spurious response:
• Adjacent channel selectivity:
• Audio output power:
• Hum and noise:
• Audio frequency response:
87
TX 156.025 ~ 157.425 MHz
RX 156.050 ~ 163.275 MHz
DSC (CH70) 156.525 MHz
AIS1 161.975 MHz
AIS2 162.025 MHz
16K0G3E (FM), 16K0G2B (DSC), 16K0GXW (AIS)
–20°C ~ +60°C, –4ºF ~ +140ºF
TX high (25 W) 5.5 A maximum
RX Maximum audio 1.5 A maximum (HM-195 × 1)
4.5 A maximum
(RX Hailer 4 Ω Load and HM-195 × 3)
Negative ground 13.8 V DC (11.7 ~ 15.9 V DC)
50 Ω nominal
Transceiver
Command microphone 67.5 (W) × 144.5 (H) × 37 (D) mm
Transceiver
Command microphone 400 g, 14.1 oz
25 W or 1 W
Variable reactance frequency modulation
Less than –70 dBc (High Power)
Less than –56 dBc (Low Power)
±0.5 kHz
More than 70 dB
Less than 10 % (at 60% Deviation)
More than 40 dB
+1 dB to –3 dB of 6 dB octave from 300 Hz to 3000 Hz
Double conversion superheterodyne
FM –13 dBμ Typ. at 12 dB SINAD
DSC (CH70) –7 dBμ emf Typ. (1% BER)
AIS –115 dBm Typ. (20% PER)
Less than –7 dBμ
FM More than 70 dB
DSC (CH70) More than 68 dBμ emf (1% BER)
AIS More than –55 dBm (20% PER)
FM More than 70 dB
DSC (CH70) More than 73 dBμ emf (1% BER)
FM More than 70 dB
DSC (CH70) More than 73 dBμ emf (1% BER)
AIS More than –50 dBm (20% PER)
Command microphone 2 W (at 10% distortion with 4 Ω)
External Speaker
More than 40 dB
+1 dB to –3 dB of –6 dB octave from 300 Hz to 3000 Hz
216 (W) × 79 (H) × 113 (D) mm
8.5 (W) × 3.1 (H) × 4.4 (D) in
2.7 (W) × 5.7 (H) ×1.5 (D) in
890 g, 2 lb
15 W (with 4 Ω)
