8 Peripherals
This chapter describes the peripherals used in the desktop and deskside systems, including:
u
RAID section
u
CD-ROM drive
u
Disk drives (1 GB, 2 GB, 4 GB)
u
Floppy disk drive
u
Combo drive
RAID Section
The following figure shows the RAID Section (MESAN15) assembly, used in TDZ-610 and some
InterServe 605 systems.
J12
J6
MSMT323
JP8
J11
J5
J3
J2
MSMT321
JP7
J1
J1
MSMT322
