Avoiding Electrostatic Discharge - Intergraph TD-x10 System Reference Manual

2
2. Lift up the top cover above the ISA I/O panel and pull it up and back.
3. Set the top cover aside. The following figure shows inside the base unit.
Peripheral
Brace
Riser Card

Avoiding Electrostatic Discharge

Some of the sensitive components inside the base unit can be damaged by static electricity. To
minimize this possibility, take the following precautions when working with the internal components of
the system.
u
To maintain ground, do not unplug the power cord from the base unit, AC outlet, or UPS.
u
Touch the bare metal of the base unit to discharge any accumulated electrostatic charge.
u
Do not service the system on surfaces known to have high electrostatic buildup, such as rugs and
carpets. Work on a static-safe surface instead.
Plunger
System Hard Disk
Drive Bracket
System
Board
Memory Sockets
ISA I/O Panel
SCSI Terminator
Power Supply
Card
CD-ROM
Drive
Floppy
Disk Drive
