For InterServe 635 and 645 systems, the power cable MCBL048A from MPCBD17 J5 connects to the
power connector. Refer to the table "J5, MCBL048A, Main Power" on page 72 for the cable pinout.
Peripherals
Internal RAID Section (MESAN15)
The following figure shows the MESAN15 assembly.
J12
J6
Cable Routing for InterServe 615, 625 Systems Using the MPCBD13 Board
From
J12, MSMT323
J6, MSMT323
JP8, MSMT323
MSMT323
JP8
J11
J5
Cable
P4
P6
MCBL057A
J3
J2
MSMT321
JP7
To
MPWS131
MPWS131
MPCBD13, J18
J1
J1
MSMT322
81
