To attach a reusable antistatic wrist strap:
1. Attach the wrist strap to the ground loop above the ISA slots on the back of the base unit.
2. Slip the elastic end of the wrist strap snugly around your bare wrist.
NOTE The metal conductor bead in the elastic must contact bare skin.

Closing the Base Unit

To close the base unit:
1. Remove the antistatic wrist strap from the ground loop inside the base unit.
2. Replace the PCI access panel if removed.
3. Set the base unit in the upright position.
4. Replace the left or right side panel if removed.
5. Replace the top cover. Ensure the top cover is completely installed so the safety interlock switch
engages. If the cover is not properly installed, the system will not start.
6. Replace the footstands.
CAUTION After servicing or upgrading the system, always replace all panels and covers. T he panels and covers
ensure the system maintains proper air flow, so internal components do not overheat. Overheated
components may fail prematurely and may be dangerous to touch. The panels and covers also ensure
electromagnetic interference (EMI) emissions are kept to levels below the standard requirements.
