Power Supply

Product Model Number

The model number on the back of the base unit identifies the hardware configuration when shipped
from Intergraph. The module number does not identify changes made by resellers or other changes
made after the unit has been installed. Individual digits are defined as follows:
Digit
1 - Series
2 - Processor Type
3 - Graphics
4 - Chassis
5 - Memory
6 - Peripheral Drives
7 - Disk Drives
8 - Operating System
9 - Revision
Desktop: 90-132 VAC or 180-264 VAC; 47-63 Hz input
TDZ: 300 Watts, manual-ranging
TD, InterServe: 200 Watts, manual-ranging
Deskside: 90-132 VAC or 180-264 VAC; 47-63 Hz input, 539 Watts,
auto-ranging
Meaning
P: Desktop
M: Single 180 MHz CPU with 256 KB cache
T: Dual 180 MHz CPU with 256 KB cache
H: Single 200 MHz CPU with 256 KB cache
J: Dual 200 MHz CPU with 256 KB cache
F: Quad 200 MHz CPU with 256 KB cache
G: Dual 200 MHz CPU (Quad ready) with 256 KB cache
5: G95
7: Millennium II with 4 MB RAM
D: Millennium II with 8 MB RAM
E: Millennium II with 12 MB RAM
M: Z10
0: TD/TDZ-310, TD/TDZ-410, InterServe 305
1: InterServe 605
N: TDZ-610 with RAID, InterServe 605 with RAID
Q: StudioZ
4: 32 MB
6: 64 MB
7: 128 MB
3: CD-ROM drive and floppy disk drive
4: CD-ROM and combo drive
2: 1 GB
3: 2 GB
4: 4 GB
7: 2 GB with 4 GB AV drive (StudioZ)
L: 4 GB with 4 GB AV drive (StudioZ)
2: Windows NT Workstation
3: Windows 95
7: Windows NT Server
Variable
Q: Deskside system
Q: Z13
R: Z25
S: Z13GT with 32 MB RAM
T: Z25GT with 64 MB RAM
Z: Intense 3D
9: 256 MB
B: 512 MB
C: 1 GB
