Note the following items on the combo drive.
u
The ISA bus connector J3 uses cable MCBL084A and connects to J32 on the system board.
u
The ISA bus connector J6 uses cable MCBL084A and connects to J33 on the system board.
u
The converter connector J4 uses cable MCBLZ230 to J2 on the combo drive. The following table
shows the pinout of MCBLZ230.
Pin
Signal
1
VCC
2
INDEX-
3
VCC
4
DRV1-
5
VCC
6
DSKCHG
7
No connect
8
No connect
9
RPM
Pin
Signal
10
MTR1-
11
No connect
12
DIR
13
No connect
14
STEP-
15
Ground
16
WDATA-
17
Ground
18
WGATE-
Pin
Signal
19
Ground
20
TRK0-
21
Ground
22
WRPRT-
23
Ground
24
RDATA-
25
Ground
26
HDSEL
