68
4. Any combination of +3.3 V, +5.1 V, and +12 V do not exceed their maximum or 539 watts of total
power.
5. The sum of Initial Setting Tolerance and Line/Load Regulation does not exceed 3% for the
+3.3 V output, 3% for the +5.1 V output, 5% for the +12.0 V output, and 10% for the negative
output voltages.

Cable Connectors

The following table shows the cable connectors from the power supply that connect to the riser card
and to the devices in the system.
The following table shows the cable connectors from the power supply that connect to the riser card
and to the devices in the system.
Connector
P1
P2
P3
P4
P5

P1 Pinout

Pin Signal
1 +3.3V
2 +3.3V
3 +3.3V
4 Ground
5 Ground
6 Ground
7 +3.3V
8 +3.3V
9 +5V
10 Ground
11 +5V
12 Ground

P2 - P8 Pinout

Pin Signal
1 +12V
2 Return
3 Return
4 +5V
Device
Riser Card
CD-ROM Drive
Auxiliary Drive
Auxiliary Drive
(or RAID section)
Auxiliary Drive
Wire Color
Orange
Orange
Orange
Black
Black
Black
Orange
Orange
Red
Black
Red
Black
Wire Color
Yellow
Black
Black
Red
Connector Device
P6 Auxiliary Drive
(or RAID section)
P7 Auxiliary Drive
P8 Auxiliary Drive
P9 Combo Drive
Pin Signal Wire Color
13 +5V Red
14 Ground Black
15 Ground Black
16 +5V Red
17 Ground Black
18 -12V Blue
19 +5V Red
20 -5V Red
21 Ground Black
22 +12V Yellow
23 Ground Black
24 Power Green
Good
