Intergraph TD-x10 System Reference Manual page 46

36
4. Remove the existing SIMMs from their sockets before adding new ones.
5. Remove the SIMMs from their antistatic bag and install them in this order:
u
If you are installing two SIMMs, install them in the Bank 0 sockets.
u
If you are installing four SIMMs, install them in the Bank 1 sockets first, and then in the Bank
0 sockets.
u
If you are installing eight SIMMs, install the first SIMM in Bank 3 socket J58. Install each
remaining SIMM in the next empty socket until Bank 0 socket J51 is the last socket populated.
Top Screw
Board Guide
Assembly
Side Screw
PCI Slot 6
Board Guide
