Scsi Pinout; Parallel Pinout - Intergraph TD-x10 System Reference Manual

62

SCSI Pinout

50
26
Note Pins 12, 13, 14, 37, and 39 are not connected; all other pins not listed are connected to ground.

Parallel Pinout

14
25
Pin
26
25
27
28
29
30
31
32
33
34
38
41
1 43
44
45
46
47
48
49
50
1
Pin Signal
1 -Strobe
2 Data 0
3 Data 1
4 Data 2
5 Data 3
6 Data 4
7 Data 5
8 Data 6
13
9 Data 7
Signal
Command Data-0
Command Data-1
Command Data-2
Command Data-3
Command Data-4
Command Data-5
Command Data-6
Command Data-7
Command Data Parity
Terminator Power
Attention
Busy
Acknowledge
Reset
Message
Select
Command
Request
Input/Output
Pin Signal
10 -ACK -
Acknowledge
11 Busy
12 PE - Paper Empty
13 +Select
14 -Auto FDXT -
Auto Feed
15 -Error
16 -Init - Start
17 -SLCTIN - Select
18-25 Ground
