70
Pin
12,14,28
16
J16, Power On LED
Pin
Signal
1
Pwrgood
2
Ground
J17, Alarm Silence Button
Pin
Signal
1
Alarm reset
2
Ground
J18, Drive Installed
Pin
Signal
J18 - 1
Drive 1
J18 - 2
Drive 2
J18 - 3
Drive 3
J19, Drive Installed
Pin
Signal
J19 - 1
Drive 4
J19 - 2
Drive 5
J19 - 3
Drive 6
J20, Auxiliary LED
Pin
Signal
1
Remote On/Off In
2
Remote On/Off Out
3
LED Ground
J40, Channel Mode LED
Pin
Signal
1
Disk bad
2
Ground
3
Disk good
Signal
Pin
No Connect
32
Pwrbad
Wire Color
Black
Black
Wire Color
Red
Black
Wire Color
Brown
Black
Red
Wire Color
Brown
Black
Red
Wire Color
Black
Black
Orange
Wire Color
Black
Black
Orange
Signal
Drive 2 Status
Pin
Signal
Remaining
Ground
