  • Page 1 InterServe 9000 System Reference September 1998 DHA031300...
  • Page 2 All warranties given by Intergraph Computer Systems about equipment or software are set forth in your purchase contract. Nothing stated in, or implied by, this document or its contents shall be considered or deemed a modification or amendment of such warranties.

  • Page 3: Table Of Contents

    Contents Part I: User’s Guide..................... 9 1 Chassis Description ..................11 Chassis Feature Summary....................12 Chassis Front Controls and Indicators ...............13 Chassis Back Controls and Features .................14 Chassis Side View......................15 Peripherals..........................16 3.5-inch Diskette Drive ....................16 3.5-inch Hard Drive Bays....................16 5.25-inch Removable Media Device Bays ..............16 Power Supplies ........................17 System Cooling ........................17 Chassis Security .........................17...
  • Page 4 Security Menu ......................40 Server Menu.......................41 Boot Menu ........................42 Exit Menu ........................43 Using the System Setup Utility ....................44 When to Run the SSU ....................44 What You Need to Do ....................45 Running the SSU .......................45 Customizing the SSU ....................47 Launching a Task .......................47 Resource Configuration Add-in (RCA) Window ............48 Multiboot Options Add-in ....................49 Security Add-in ......................50...
  • Page 5 Part II: Service Technician’s Guide ..............79 5 Working Inside the System ................81 Tools and Supplies Needed ....................81 Safety: Before You Remove the Access Cover ..............81 Warnings and Cautions .......................82 Access Cover ........................83 Removing the Access Cover ..................83 Installing the Access Cover ..................84 Opening the Subchassis and Electronics Bay ..............84 Add-in Boards ........................86 Installing an Add-in Board ..................86...
  • Page 6 7 Solving Problems..................115 Resetting the System ......................115 Initial System Startup Checklist ..................115 Running New Application Software Checklist ..............116 Faulty Equipment Checklist ....................116 More Problem-solving Procedures ..................117 Preparing the System for Diagnostic Testing ............117 Using PCDiagnostics....................117 Monitoring POST ......................118 Verifying Proper Operation of Key System Lights ............118 Confirming Loading of the Operating System ............118 Specific Problems and Corrective Actions ................118 Power Light Does Not Light ..................119...
  • Page 7 Baseboard Jumpers ......................143 General Procedure to Change Jumper Setting ............144 CMOS Clear Jumper ....................144 Password Clear Jumper ...................145 Recovery Boot Jumper .....................145 System I/O Addresses ......................146 Memory Map Addresses ....................148 Interrupts...........................149 Video Modes ........................150 A Equipment Log and Worksheets ..............155 Equipment Log ........................155 Configuration Worksheets ....................157 Current Usage ......................157...
  • Page 8 viii...

  • Page 9: Part I: User's Guide

    Part I: User’s Guide 1 Chassis Description 2 Baseboard Description 3 Configuration Software and Utilities 4 Exchanging SCSI Hard Drives and Power Supplies...

  • Page 11: Chassis Description

    1 Chassis Description The InterServe 9000 either stands upright (pedestal mode) or installs in a rack (rack mode). Figures 1 and 2 show examples of these configurations. NOTE The faceplate appearance may vary slightly from the figures shown. OM08000 OM08045 Figure 1.

  • Page 12: Chassis Feature Summary

    Chassis Feature Summary The system’s galvanized metal chassis minimizes electromagnetic interference (EMI) and radio frequency interference (RFI). The removable access cover is attached to the chassis with two screws. A front subchassis and an electronics bay (at the rear of the main chassis) both rotate outward and can be removed entirely to provide easy access to internal components.

  • Page 13: Chassis Front Controls And Indicators

    Chassis Front Controls and Indicators OM08001 Figure 3. Front Controls and Indicators A. External drive bay (5¼-inch); CD-ROM drive B. Diskette drive C. Power On/Off button (holding down this button for more than four seconds causes a power-button override to the PIIX4E when you release the button) D.

  • Page 14: Chassis Back Controls And Features

    Chassis Back Controls and Features OM08002 Figure 4. Back Controls and Indicators A. Parallel port † B. Video Graphics Array (VGA) monitor connector C. Serial port A, COM1 D. Serial port B, COM2 E. Mouse connector Keyboard connector G. Universal serial bus connector H.

  • Page 15: Chassis Side View

    Chassis Side View OM08017 Figure 5. Chassis Side View A. Front swing-out subchassis B. Diskette drive C. Main chassis D. Power backplane E. Power supply(s) Baseboard G. Lift-out electronics bay H. 5.25-inch device bay SCSI hard drive bay Foam cover K.

  • Page 16: Peripherals

    Peripherals 3.5-inch Diskette Drive The 3.5-inch diskette drive in the 3.5-inch peripheral bay supports 720 KB, and 1.44 MB media. The drive is accessible from the front of the system. 3.5-inch Hard Drive Bays The system was designed to allow the user to install a Redundant Array of Independent Disks (RAID).

  • Page 17: Power Supplies

    (up to three) and two fans for cooling hard drives. NOTE The access cover must be on the system for proper cooling. Chassis Security For information on security features on the InterServe 9000, see “System Security” on page 27.
  • Page 18 Blank page...

  • Page 19: Baseboard Description

    2 Baseboard Description Baseboard Features Table 3. Baseboard Features Feature Description Processor Installed: Up to four Pentium II Xeon processors, packaged in single edge contact (SEC) cartridges and installed in 330-pin Slot 2 processor connectors, operating at 1.8 V to 3.5 V. The baseboard’s voltage regulator is automatically programmed by the processor’s voltage ID (VID) pins to provide the required voltage.

  • Page 20: Baseboard Features

    Baseboard Features Baseboard Connector and Component Locations OM08022 Figure 6. Baseboard Connector and Component Locations Wide SCSI B connector (J9J1) for external VRM connector for processor 1 (J4A1) support System jumpers (J6J1) Processor 1 Slot 2 connector (J9A1) Hard drive input LED connector (J6J3) W.

  • Page 21: Processor

    Processor Each Pentium II Xeon processor is packaged in a single edge contact (SEC) cartridge. The cartridge includes the processor core with an integrated 16 KB primary (L1) cache; the secondary (L2) cache; a thermal plate; and a back cover. The processor implements the MMX technology and maintains full backward compatibility with the 8086, 80286, Intel386, Intel486, Pentium, and Pentium Pro processors.

  • Page 22: Memory

    Main memory resides on an add-in board, called a memory module, designed specifically for the InterServe 9000. The memory module contains slots for 16 dual in-line memory modules (DIMMs), each of which must be at least 32 MB, and is attached to the baseboard through a 242- pin connector.
  • Page 23 The top of physical memory is a maximum of 4 GB (to FFFFFFFFh). NOTE The InterServe 9000 system is configured to support 4 GB of addressable memory. Some operating systems and application programs use base memory while others use both conventional and extended memory.

  • Page 24: Super I/O Chip

    Super I/O Chip The 87309 device supports two serial ports, a parallel port, diskette drive, and PS/2-compatible keyboard and mouse. The system provides the connector interface for each port. Serial Ports Both serial ports are relocatable. By default, port A is physically the top connector, port B is the bottom connector.

  • Page 25: Video

    100 Hz. You can not add video memory to the InterServe 9000. Depending on the environment, the controller displays up to 16.7 M colors in some video resolutions. It also provides hardware- accelerated bit block transfers (BITBLT) of data.

  • Page 26: Ide Controller

    IDE Controller IDE is a 16-bit interface for intelligent disk drives with AT disk controller electronics onboard. The PCI/ISA/IDE Accelerator, called PIIX4E, is a multifunction device on the baseboard that acts as a PCI-based Fast IDE controller. The device controls: PIO and IDE direct memory access (DMA)/bus master operations Mode 4 timings Transfer rates up to 22 MB/sec...

  • Page 27: System Security

    The BMC provides an ISA host interface to SDRR information, so software running on the server can poll and retrieve the current status of the platform. A shared register interface is defined for this purpose. SEL contents can be retrieved after system failure for analysis by field service personnel using system management tools like Intel’s LANDesk Server Manager.

  • Page 28: Software Locks Via The Ssu Or Bios Setup

    Software Locks via the SSU or BIOS Setup The SSU provides a number of security features to prevent unauthorized or accidental access to the system. Once the security measures are enabled, access to the system is allowed only after the user enters the correct password(s).
  • Page 29 Table 5. Software Security Features Feature Description Put the system into How to enter secure mode: secure boot mode Setting and enabling passwords automatically puts the system into secure mode. If you set a hot-key combination (through the SSU or Setup), you can secure the system simply by pressing the key combination.
  • Page 30 Table 5. Software Security Features (continued) Feature Description Control access to using To control access to setting or changing the system configuration, set an the SSU: set administrator password and enable it through Setup or the SSU. administrator password If both the administrator and user passwords are enabled, either can be used to boot the system or enable the keyboard and/or mouse, but only the administrator password allows changes to Setup and the SSU.

  • Page 31: Configuration Software And Utilities

    3 Configuration Software and Utilities This chapter describes POST and system configuration utilities. The table below briefly describes the utilities. Table 6. Configuration Utilities Utility Description and brief procedure Page BIOS Setup If the system does not have a diskette drive, or the drive is disabled or misconfigured, use Setup to enable it.

  • Page 32: Power-On Self Test

    Power-on Self Test Each time you turn on the system, POST starts running. POST checks the baseboard, processors, memory, keyboard, and most installed peripheral devices. During the memory test, POST displays the amount of memory it is able to access and test. The length of time needed to test memory depends on the amount of memory installed.

  • Page 33: Using Bios Setup

    Using BIOS Setup This section describes the BIOS Setup options. Use Setup to change the system configuration defaults. You can run Setup with or without an operating system being present. Setup stores most of the configuration values in battery-backed CMOS; the rest of the values are stored in flash memory.

  • Page 34: Setup Menus

    In a fourth condition, when CMOS Non-Volatile Random Access Memory (NVRAM) has been corrupted, you will see other prompts but not the <F2> prompt: Warning: cmos checksum invalid Warning: cmos time and date not set In this condition, the BIOS will load default values for CMOS and attempt to boot. Setup Menus Setup has six major menus and several submenus: 1.

  • Page 35: Main Menu

    When you see this: What it means: On screen, the phrase Press Enter appears next to Press <Enter> to display a submenu that is either a the option. separate full-screen menu or a pop-up menu with one or more choices. The rest of this section lists the features that display onscreen after you press <F2>...
  • Page 36 Primary Master and Slave Submenu In the following table, the features other than “Type” appear only for Type Auto if a drive is detected. Table 9. Primary IDE Master and Slave Submenu Feature Choices Description Type Auto Auto allows the system to attempt autodetection of the None drive type.

  • Page 37: Advanced Menu

    Keyboard Features Submenu Table 10. Keyboard Features Submenu Feature Choices Description Num Lock Auto Selects power on state for Num Lock. Key Click Disabled Enables or disables key click. Enabled Keyboard auto-repeat rate 30, 26.7, 21.8, 18.5, 13.3, Selects key repeat rate. 10, 6, or 2 per second Keyboard auto-repeat delay 1/4 sec...

  • Page 38: Pci Configuration Submenu

    PCI Configuration Submenu The PCI Configuration menu contains selections that access other submenus. PCI Device, Embedded SCSI Submenu Table 12. PCI Device, Embedded SCSI Submenu Feature Choices Description Option ROM Scan Enabled Enables option ROM scan of the selected device. Disabled Enable Master Disabled...
  • Page 39 I/O Device Configuration Submenu Table 14. I/O Device Configuration Submenu Feature Choices Description Serial Port A Disabled Enabled Auto Auto forces BIOS to configure the port. operating system OS Controlled displays when operating system controls the port. Controlled Base I/O Address Selects the base I/O address for COM port A.

  • Page 40: Security Menu

    Advanced Chipset Control Submenu Table 15. Advanced Chipset Control Submenu Feature Option Description Address Bit Permuting Disabled To be enabled, there must be a power of 2 number of Enabled rows, all rows must be the same size, and all populated rows must be adjacent and start at row 0.

  • Page 41: Server Menu

    Feature Choices Description User Password is Clear Status only; user cannot modify. Once set, this can be disabled by setting it to a null string or by clearing password jumper on baseboard (see “Baseboard Jumpers,” page 143). Set Administrative Press Enter When the <Enter>...

  • Page 42: Boot Menu

    System Management Submenu Table 18. System Management Submenu Feature Choices Description Server Management Mode Disabled Enabled loads Server Management Interrupt handler, Enabled which handles system errors. System Event Logging Disabled Enabled forces BIOS and BMC to log system events. Enabled Clear Event Log Disabled Enabled clears the system event log.

  • Page 43: Exit Menu

    Table 20. Boot Menu Feature Choices Description Floppy Check Disabled If Enabled, system verifies diskette type on boot. Enabled Disabled results in a faster boot. Multi-boot Support Disabled Enable this option only if the total number of hard Enabled drives is less than eight. Boot Device Priority Enters submenu.

  • Page 44: Using The System Setup Utility

    Table 23. Exit Menu Choices Description Exit Saving Changes Exits after writing all modified Setup item values to NVRAM. Exit Discarding Changes Exits leaving NVRAM unmodified and continues POST. User is prompted if any of the Setup fields were modified. Load Setup Defaults Loads default values for all Setup items.

  • Page 45: What You Need To Do

    The SSU is PCI-aware and complies with the ISA Plug and Play specifications; it works with any compliant configuration (.CFG) files supplied by the peripheral device manufacturer. The baseboard comes with a .CFG file describing the characteristics of the board and the system resources it requires.

  • Page 46: Starting The Ssu

    Starting the SSU The SSU is a collection of task-oriented modules plugged into a common framework called the application framework (AF). The AF provides a launching point for individual tasks and a location for setting customization information. 1. Turn on your video display and your system. 2.

  • Page 47: Customizing The Ssu

    Customizing the SSU You can customize the user interface according to your preferences. The AF sets these preferences and saves them in the AF.INI file so that they take effect the next time you start the SSU. Use these four user-customizable settings: Color—lets you change the default colors associated with different items on the screen to predefined color combinations.

  • Page 48: Resource Configuration Add-In (Rca) Window

    Resource Configuration Add-in (RCA) Window The RCA provides three major functions: Creates representations of devices that cannot be discovered by the system (ISA boards) Modifies the contents of the system by adding and removing devices Modifies the resources used by devices You can use the RCA window to define or add an ISA board by clicking on the appropriate button.

  • Page 49: Multiboot Options Add-In

    Adding and Removing ISA Boards Adding and removing boards through the RCA provides a way for the RCA to run its conflict detection algorithms on the resources requested by the boards. This alerts you to any possible problems with that particular board in the current configuration. To add an ISA board: 1.

  • Page 50: Security Add-In

    Security Add-in In this window, you can set the User and Administrator passwords and security options. To Set the User Password 1. Click <User Password>. 2. Enter the password in the first field. 3. Confirm the password by entering it again in the second field. To Change or Clear the User Password 1.
  • Page 51 The SEL viewer’s main window provides access to features of the add-in. Each option included on the main menu supports an accelerator key. Accelerator keys are indicated by an underlined letter in the text listing the option. The main window i ncludes support to display the following information for each SEL entry: record identifier, event type, time stamp information, generator identifier, emv revision, sensor type, sensor number, and event description.

  • Page 52: Sensor Data Record Manager Add-In

    Sensor Data Record Manager Add-In In this window, you can: Examine all SDR records through the BMC (in either Hex or Verbose mode) Examine SDR records by Record type (in either Hex or Verbose mode) Examine SDR records from a previously stored binary file (in either Hex or Verbose mode) Save the SDR records to a file (in either text or binary form) The SDR Manager can display SDR records in either raw form (hexadecimal) or in an interpreted, easy-to-understand textual form (verbose).

  • Page 53: Field Replaceable Unit Manager Add-In

    Table 25. SDR Manager Menus Menu Options File Open FRU: Opens FRU data from a previously saved file Save SDR: Saves SDR data to a file in binary raw or verbose text format Exit: Quits the SDR Manager View SDR Info: Displays SDR information as returned by the GetSDRInfo interface of the BMC All Records: Displays all records in the SDR repository By Record: Displays all records in the SDR repository, sorted by record type Settings...

  • Page 54: Exiting The Ssu

    Table 26. FRU Manager Menus Menu Options File Open FRU: Opens FRU data from a previously saved file Save FRU: Saves FRU data to a file in binary raw or verbose text format Exit: Quits the FRU Manager View FRU Info: Displays FRU information of the selected device All FRU Areas: Displays FRU areas of all devices By Device Type: Displays FRU areas sorted by device type Settings...
  • Page 55 Figure 12. EMP Console in Command State Redirect state—the EMP console serves as a PC ANSI terminal window for BIOS console redirection. Commands typed in this terminal window are transmitted through BIOS to the server’s console, and text displayed on the server console is displayed on the EMP console’s terminal window.

  • Page 56: Emp Console Requirements

    Table 27. EMP Console Access Modes (Server Configured for Console Redirect) Mode Server is powered off During POST After OS boots Disabled Redirect window appears, but is blank Redirect window Redirect window Pre-boot EMP commands available Redirect window* Redirect window Always Active EMP commands available Redirect window*...

  • Page 57: Setting Up The Server For The Emp

    Setting Up the Server for the EMP To use the EMP, you must configure BIOS with specific settings. Enter these settings in two submenus of the BIOS Server Menu: the System Management Submenu and the Console Redirect Submenu. The section above on BIOS settings shows all available options. The sections below focus on the settings that must be configured to use the EMP.

  • Page 58: Status Bar

    Toolbar The tool bar buttons combine server control and management plug-in options available from the Connect and Action Menus. Connects to a selected server. Disconnects from the currently connected server. Powers the selected server on or off. Resets the selected server. Opens the SEL viewer.

  • Page 59: Server Control Operations

    FRU Viewer: Opens the FRU viewer. Phonebook: Opens the phonebook dialog. Help: Provides version information and help topics for the EMP console. Server Control Operations Three server control operations are available from the menu or toolbar of the main EMP console window, remote server connection, powering the server on and off, and resetting the server.
  • Page 60 Cancel: Exit the Connect dialog with no action taken. Help: Display dialog-level help information. Power On/Off the Server Remotely Selecting Power On/Off from the Action Menu allows you to power the server on or off, with POST power-up options. It generates the Power on/off dialog. Figure 15.

  • Page 61: Phonebook

    Options available in the dialog are: System Reset: Resets the server with the selected POST reset options. This operation is not allowed if the server is configured in restricted mode for EMP operations. Option Group: Sets the POST reset option that will be effective after reset. The options are EMP active or BIOS redirection.

  • Page 62: Management Plug-Ins

    Cancel: Exits the dialog with no action taken. Help: Displays dialog-level help information. Management Plug-ins System Event Log Viewer The SEL viewer can display records in either hexadecimal or text (verbose) form. These options are available through the SEL viewer: View the SEL from a file Save the SEL to a file View SEL summary information...
  • Page 63 Settings: Lets you change several operating parameters for the SEL viewer. This menu displays the following suboptions: Display HEX/Verbose: Toggles between HEX mode and interpreted mode of displaying SEL records. Output Text/Binary: Specifies whether SEL data will be saved to the file in binary format or verbose format.

  • Page 64: Frusdr Load Utility

    Set FRU display mode to either Hex or verbose mode Close the FRU viewer Exit the EMP console FRU Viewer Menu Options The following menu options are on the FRU viewer menu bar: File Close: Closes the FRU viewer. Exit: Exits the EMP console. View Display all Records: Displays all FRU data, which consist of chassis, board, and product information.

  • Page 65: What You Need To Do

    What You Need to Do You can run the utility directly from the configuration software CD or from diskettes you create from the CD. If you choose to run the FRUSDR load utility from a diskette, you must copy the utility from the CD and follow the instructions in the included README.TXT file.

  • Page 66: Displaying Usage Information

    Displaying Usage Information When the utility is run with the -? or -h command line flags, the following message displays when the verbose flag -v is added to the help command: FRUSDR Load Utility Version 2.1 Revision R.1.1 Usage: frusdr -? or -h Displays usage information -d {dmi,fru,sdr}...

  • Page 67: Using Specified Cfg File

    Displaying FRU Area The FRU area is displayed in ASCII format when the field is ASCII or as a number when the field is a number. Each FRU area displayed is headed with the FRU area designated name. Each field has a field name header followed by the field in ASCII or as a number.

  • Page 68: Cleaning Up And Exiting

    Microsoft’s World Wide Web and FTP sites free of charge. CAUTION If Intergraph provides a Service Pack through the World Wide Web or with a product or system, it has been certified against Intergraph hardware as described in the announcement of its availability. If you obtain a Service Pack from any other source, be aware that it may not be certified against your Intergraph hardware.

  • Page 69: Upgrading The Bios

    Upgrading the BIOS You may want to update the system’s current BIOS with a new version to take advantage of fixes or enhancements. Obtain the FlashNX utility from the Support pages of the Intergraph Computer Systems World Wide Web site (www.intergraph.com/ics/).

  • Page 70: Recovering The Bios

    Upgrading the Firmware You may want to update the system’s firmware with a new version to take advantage of fixes or enhancements. Obtain the FirmwareNX utility from the Support pages of the following Intergraph Computer Systems World Wide Web site: http:www.intergraph.com/ics...

  • Page 71: Installing Video Drivers

    For more information on updating the firmware, see the file delivered with the README FirmwareNX product. Installing Video Drivers After configuring the system, you need to install video drivers to take full advantage of the features of the onboard CL-GD5480 super VGA video controller. Install the CIRRUSNTDRV driver from the backup media.

  • Page 73: Exchanging Scsi Hard Drives And Power Supplies

    4 Exchanging SCSI Hard Drives and Power Supplies SCSI Hard Disk Drives The system supports a variety of LVD and single-ended SCSI devices. As shipped from the supplier, the system might contain no hard disk drives. Contact your sales representative or dealer for a list of approved SCSI devices.

  • Page 74: Hot-Swapping A Scsi Hard Disk Drive

    Hot-swapping a SCSI Hard Disk Drive A bank of six yellow LEDs on the front panel monitors the drive status of each RAID drive in the hot-docking bay. Each LED corresponds directly to a drive, so that the upper-most LED reflects activity in the upper-most drive.
  • Page 75 9. Gently push the drive into the bay. To engage the latch, the carrier handle should be approximately at a 45 angle from the vertical front of the chassis. As you push the drive into the bay, the two rounded notches in the carrier handle (B in Figure 20) slide onto the two round pegs inside the drive bay (A in Figure 20).

  • Page 76: Installing Heatsinks On High-Power Drives

    Installing Heatsinks on High-Power Drives If you plan to use SCSI drives whose power exceeds 15 watts, you must install heatsinks on those drives. CAUTION If you install high-power drives, you must also install additional system fans. This requires that you work inside the chassis and that you are a technically qualified service technician.

  • Page 77: Power Supply

    Power Supply WARNINGS Hazardous conditions, power supply: Hazardous voltage, current, and energy levels are present inside the power supply. There are no user-serviceable parts inside it; servicing should be done by technically qualified personnel. Removing a Power Supply 1. Disconnect the AC power cable from the system. 2.

  • Page 78: Installing A Power Supply

    Installing a Power Supply 1. Slide the power supply into its bay. 2. With even force on the flared, vertical edges, push toward the front of the system until the edges rest against the rear of the chassis and the supply engages its connector. 3.

  • Page 79: Part Ii: Service Technician's Guide

    Part II: Service Technician’s Guide 5 Working Inside the System 6 Upgrading Baseboard Components 7 Solving Problems 8 Technical Reference A Equipment Log and Worksheets B Regulatory Specifications C Warnings...

  • Page 81: Working Inside The System

    5 Working Inside the System Tools and Supplies Needed Phillips (cross-head) screwdriver (#1 and #2 bit). Small flat-bladed screwdriver. Jumper removal tool or needle-nosed pliers. Antistatic wrist strap and conductive foam pad (recommended). Pen or pencil. Equipment log: as you integrate new parts into the system, add information about them to your equipment log (page 155).

  • Page 82: Warnings And Cautions

    Warnings and Cautions These warnings and cautions apply whenever you remove the access cover of the system. Only a technically qualified person should integrate and configure the system. WARNINGS System power on/off: The on/off button (a convex button) on the front panel DOES NOT turn off the system AC power.

  • Page 83: Access Cover

    Access Cover Removing the Access Cover You need to remove the system access cover, and in some cases the front bezel, to reach components inside the system. Facing the front of the system, the access cover is on the right side for pedestal-mode servers, and on the top for rack-mode servers.

  • Page 84: Installing The Access Cover

    Installing the Access Cover 1. Before replacing the access cover, check that you have not left loose tools or parts inside the system. 2. Check that cables, add-in boards, and other components are properly installed. 3. Position the cover over the chassis so that the rows of tabs align with slots in the chassis. Slide the cover toward the front of the system until the tabs on the cover firmly engage in the chassis.
  • Page 85 8. Rotate the front subchassis left, away from the main chassis, until it stops (B in Figure 24). 9. Disconnect all cabling to the electronics bay (D in Figure 24). 10. Using the vertical edge of the electronics bay as a handle, rotate the bay right, away from the main chassis, until it stops (C in Figure 24).

  • Page 86: Add-In Boards

    Add-in Boards Installing an Add-in Board CAUTIONS Do not overload baseboard: Do not overload the baseboard by installing add-in boards that draw excessive current. ESD and handling boards: Add-in boards can be extremely sensitive to ESD and always require careful handling. After removing the board from its protective wrapper or from the baseboard, place it component-side up on a grounded, static-free surface or conductive foam pad—if available.

  • Page 87: Removing An Add-In Board

    OM08019a Figure 25. Installing an Add-in Board A. ISA slot (Use half-length board only if the second onboard SCSI port is used) B. Six PCI slots (top to bottom in figure = PCI B3, B2, B1, B0, A3, and A2) C.

  • Page 88: Front Panel Board

    Front Panel Board Removing the Front Panel Board The front panel board contains the system controls and indicators. It is mounted on a snap-on standoff and a threaded standoff inside the chassis. 1. Observe the safety and ESD precautions at the beginning of this chapter. 2.

  • Page 89: Diskette Drive

    Diskette Drive Removing the Diskette Drive 1. Observe the safety and ESD precautions at the beginning of this chapter. 2. Remove the access cover (see page 83). 3. Disconnect the power and signal cables from the diskette drive. The connectors are keyed for ease in reconnecting them to the drive.

  • Page 90: Installing The Diskette Drive

    OM08044 Figure 28. Removing the Diskette Drive from the Carrier Installing the Diskette Drive 1. Remove the new 3.5-inch diskette drive from its protective wrapper, and place it component-side up on an antistatic surface. Record the drive model and serial numbers in your equipment log (see page 155).

  • Page 91: Peripheral Drives

    Peripheral Drives Drive Cabling Considerations This section summarizes device cabling requirements and constraints. The number of devices you can install depends on: The number supported by the bus The number of physical drive bays available The height of drives in the internal bays (1-inch or 1.6-inch high) The combination of SCSI and IDE devices IDE Requirements An 18-inch long IDE cable that supports two drives is standard in the system.

  • Page 92: Installing A 5.25-Inch Peripheral In The Front Bay

    CAUTIONS Only single-ended SCSI devices supported: The internal SCSI interface in the InterServe 9000 supports only single-ended SCSI devices on the narrow SCSI channel. Connecting differential SCSI drive types to this interface can result in electrical damage to the baseboard and peripherals.
  • Page 93 1. Observe the safety and ESD precautions at the beginning of this chapter. Also see the cabling considerations on page 91. 2. Open the front bezel by rotating its right side out and to the left. 3. Push the tab (A in Figure 30) on the left side of the EMI metal shield to the right to disengage it from the chassis.
  • Page 94 OM08013 Figure 31. Snap-in Plastic Slide Rails A. Tape drive or other removable media device B. Tab on slide rail C. Screws (4) D. Slide rails (2) 8. Position the drive so the plastic slide rails engage in the bay guide rails. Push the drive into the bay until the slide rails lock in place.

  • Page 95: Removing A 5.25-Inch Peripheral From The Front Bay

    Removing a 5.25-inch Peripheral from the Front Bay 1. Observe the safety and ESD precautions at the beginning of this chapter. 2. Open the front bezel by rotating its right side out and to the left. 3. Disconnect the power and signal cables from the drive. 4.

  • Page 96: Fans

    Fans The SC450NX server contains five removable chassis fans (and can accept up to three more) to cool the boards and removable media drives. These chassis fans connect to the front panel board and are enclosed in a removable foam assembly. The integrated power supply fan(s) provides more cooling and airflow.

  • Page 97: Installing The System Fan Assembly

    Installing the System Fan Assembly 1. Observe the safety and ESD precautions at the beginning this chapter. 2. Position the fan assembly inside the chassis so that the individual fan cables can easily reach their connectors on the front panel board. 3.
  • Page 98 Figure 34, it is the rectangle between fans 6 and 7. You must remove this piece to access the two fans it separates (pull it straight out). OM08021a Figure 34. Fan Cabling NOTE Fans 4, 5, and 8 are optional. Ask your Intergraph representative for a redundant fan kit, if desired.

  • Page 99: Installing An Individual System Fan

    Installing an Individual System Fan NOTE A general rule about correct airflow direction: The removable fan pulls air from in front of the chassis so that it flows across the boards and out the back. Thus, the fan must be oriented for the correct airflow direction. In general, the fan’s label is on the side from which air EXITS the fan.

  • Page 100: Installing Fans For High-Power Drives

    Installing Fans for High-Power Drives If you plan to use SCSI drives whose power exceeds 15 watts, you must install three additional system fans: two in the front fan assembly and one in the upper power supply bay. To perform this task, you must purchase a kit.
  • Page 101 6. Install two fans in the front fan assembly. See “Installing an Individual System Fan” on page 99. CAUTION The two fans you MUST install are numbered 6 and 7 in Figure 34 (page 98). 7. Connect the cable (D in Figure 35, page 100) from the fan you installed in the upper power supply bay to the connector on the power share board.

  • Page 103: Upgrading Baseboard Components

    6 Upgrading Baseboard Components Tools and Supplies Needed Phillips (cross-head) screwdriver (#1 and #2 bit) Small flat-bladed screwdriver Jumper removal tool or needle-nosed pliers Antistatic wrist strap and conductive foam pad (recommended) Pen or pencil Equipment log: as you integrate new parts into the system, add information about them to your equipment log (page 155).

  • Page 104: Baseboard

    Chassis covers, proper cooling, and airflow: For proper cooling and airflow, always install the chassis access cover before turning on the system. Operating the system without this cover in place can damage system parts. Installing or removing jumpers: A jumper is a small, plastic-encased conductor that slips over two jumper pins.

  • Page 105: Installing The Baseboard

    10. Remove the baseboard and place it component-side up on a nonconductive, static-free surface or in an antistatic bag. 11. Remove and save the EMI gasket that covers the I/O connectors on the board. OM08007 Figure 36. Removing the Baseboard Installing the Baseboard 1.

  • Page 106: Memory

    Memory Removing the Memory Module NOTE Make sure you run the SSU to configure ECC memory. Failure to do so might degrade the performance of the server. See “Memory” on page 22 for memory size and requirements. 1. Observe the safety and ESD precautions at the beginning of this chapter. 2.

  • Page 107: Installing The Memory Module

    Installing the Memory Module 1. Observe the safety and ESD precautions at the beginning of this chapter. 2. Holding the memory module by its edges, align the module so its edge engages in the guide rail at the back of the electronics bay. CAUTION The memory module is held in place by the 242-pin connector on the baseboard, the guide rail at the back of the electronics bay, and a plastic...

  • Page 108: Installing Dimms

    Installing DIMMs CAUTIONS Use extreme care when installing a DIMM. Applying too much pressure can damage the socket. DIMMs are keyed and can be inserted in only one way. Mixing dissimilar metals might cause memory failures later, resulting in data corruption.

  • Page 109: Processors

    1. Holding the DIMM only by its edges, remove it from its antistatic package. 2. Orient the DIMM so that the two notches in the bottom edge of the DIMM align with the keyed socket on the memory module. 3. Insert the bottom edge of the DIMM into the socket, then press down firmly on the DIMM until it seats correctly.
  • Page 110 OM08038 Figure 39. Releasing the Retention Module Bracket A. Retention module bracket B. Tab of bracket C. Latch 7. Disengage the open hinge by moving (not rotating) the entire bracket to the right. Remove the bracket and set it aside. 8.

  • Page 111: Installing A Processor

    Installing a Processor OM08040 Figure 41. Installing a Processor A. SEC cartridge B. Retention module guide rails C. Tabs on SEC. cartridge D. Processor heat sink (must face away from center of baseboard) E. Push tabs on SEC cartridge inward to seat processor NOTE If your system has less than four processors and you are ADDING one, then you must remove the termination board in the empty Slot 2 connector.

  • Page 112: Installing Processor Tabs

    4. With the tabs at the top of the SEC cartridge completely open (pulled outward, away from the center of the cartridge—C in Figure 41), slide the cartridge into the guide rails of the retention module (B in Figure 41). When done properly, the triangular ends of the tabs (with two round pegs on each) fit into the entrance to the guide rails.

  • Page 113: Replacing The Backup Battery

    Replacing the Backup Battery The lithium battery on the baseboard powers the real-time clock (RTC) for three to four years in the absence of power. When the battery weakens, it loses voltage and the system settings stored in CMOS RAM in the RTC (for example,, the date and time) may be wrong. Contact your customer service representative or dealer for a list of approved devices.
  • Page 114 OM08005 Figure 42. Replacing the Lithium Battery 1. Observe the safety and ESD precautions at the beginning of this chapter and the additional warning given on page 113. 2. Remove the access cover. 3. Insert the tip of a small flat-bladed screwdriver or equivalent under the plastic tab on the snap-on plastic retainer.

  • Page 115: Solving Problems

    7 Solving Problems This chapter helps you identify and solve problems that might occur while you are using the system. Resetting the System To do this: Press: Soft boot reset, which clears system memory and reloads the operating system. <Ctrl+Alt+Del> Clear system memory, restart POST, and reload the operating system.

  • Page 116: Running New Application Software Checklist

    Running New Application Software Checklist Problems that occur when you run new application software are usually related to the software. Faulty equipment is much less likely, especially if other software runs correctly. Does the system meet the minimum hardware requirements for the software? See the software documentation.

  • Page 117: More Problem-Solving Procedures

    More Problem-solving Procedures This section provides a more detailed approach to identifying a problem and locating its source. Preparing the System for Diagnostic Testing CAUTION Turn off devices before disconnecting cables: before disconnecting any peripheral cables from the system, turn off the system and any external peripheral devices.

  • Page 118: Monitoring Post

    Monitoring POST See Chapter 3, “Configuration Software and Utilities,” beginning on page 31. Verifying Proper Operation of Key System Lights As POST determines the system configuration, it tests for the presence of each mass storage device installed in the system. As each device is checked, its activity light should turn on briefly. Check for the following: Does the diskette drive activity light turn on briefly? If not, see “Diskette Drive Activity Light Does Not Light”...

  • Page 119: Power Light Does Not Light

    4. If you do not receive a beep code and characters do not appear, the video display or video controller may have failed. You can verify this by trying the monitor on another system or trying a different monitor on the InterServe 9000. Contact your service representative or authorized dealer for assistance.

  • Page 120: Characters Are Distorted Or Incorrect

    Characters Are Distorted or Incorrect Check the following: Are the brightness and contrast controls properly adjusted on the video display? See the manufacturer’s documentation. Are the video display signal and power cables properly installed? Is the correct monitor/video board installed for your operating system? If the problem persists, the video display may be faulty or it may be the incorrect type.

  • Page 121: Hard Disk Drive Activity Light Does Not Light

    Hard Disk Drive Activity Light Does Not Light If you have installed one or more hard disk drives in your system, check the following: Are the power and signal cables to the drive properly installed? Are all relevant switches and jumpers on the hard drive and adapter board set correctly? Is the onboard IDE controller enabled? (IDE hard drives only) Is the hard disk drive properly configured? NOTE...

  • Page 122: Problems With Application Software

    Problems with Application Software If you have problems with application software, do the following: Verify that the software is properly configured for the system. See the software installation and operation documentation for instructions on setting up and using the software. Try a different copy of the software to see if the problem is with the copy you are using.
  • Page 123 Table 30. Port-80 Codes (continued) Normal Port 80 Codes Beeps Error Initialize I/O Initialize the local bus IDE Initialize Power Management Load alternate registers with initial POST values new Restore processor control word during warm boot Initialize keyboard controller 1-2-2-3 BIOS ROM checksum 8254 timer initialization 8237 DMA controller initialization...
  • Page 124 Table 30. Port-80 Codes (continued) Normal Port 80 Codes Beeps Error Display copyright notice Display processor type and speed Initialize EISA board Test keyboard Set key click if enabled Enable keyboard 2-2-3-1 Test for unexpected interrupts Display prompt “Press F2 to enter SETUP” Test RAM between 512 and 640k Test extended memory Test extended memory address lines...
  • Page 125 Table 30. Port-80 Codes (continued) Normal Port 80 Codes Beeps Error Disable A20 address line Install CD-ROM for boot Clear huge ES segment register Search for option ROMs. One long, two short beeps on checksum failure Shadow option ROMs Set up Power Management Enable hardware interrupts Set time of day Check key lock...

  • Page 126: Post Error Codes And Messages

    POST Error Codes and Messages The following error codes and messages are representative of various conditions BIOS identifies. The exact strings and error numbers may be different from those listed here. Table 31. POST Error Codes and Messages Code Error message 0162 BIOS unable to apply BIOS update to processor 1 0163...
  • Page 127 Table 31. POST Error Codes and Messages (continued) Code Error message 8100 Processor 0 failed BIST 8101 Processor 1 failed BIST 8104 Processor 0 Internal Error (IERR) failure 8105 Processor 1 Internal Error (IERR) failure 8106 Processor 0 Thermal Trip failure 8107 Processor 1 Thermal Trip failure 8108...
  • Page 128 blank page...

  • Page 129: Technical Reference

    8 Technical Reference This section includes: Cable routing Connectors Baseboard jumpers System I/O addresses Memory map addresses Interrupts Video modes Cable Routing The following tables show cable routing from the system board connectors to the various devices in the system. Table 32.

  • Page 130: Connectors

    Connectors Figure 43 shows connector locations on the baseboard. This section provides pin information about the connectors. OM08022 Figure 43. Baseboard Layout Wide SCSI B connector (J9J1) for external VRM connector for processor 1 (J4A1) support System jumpers (J6J1) Processor 1 Slot 2 connector (J9A1) Hard drive input LED connector (J6J3) W.

  • Page 131: Main Power Connector

    Main Power Connector OM08034 Table 34. Main Power Connector Pinout Signal Wire Color Signal Wire Color +3.3 VDC Orange +3.3 VDC Orange +3.3 VDC Orange +3.3 VDC Orange +3.3 VDC Orange +3.3 VDC Orange Black Black Black Black Black Black Black +5V Standby Purple...

  • Page 132: Diskette Drive

    Diskette Drive OM08030 Table 36. Diskette Drive Connector Pinout Signal Signal FD_DIR_L FD_DENSEL FD_STEP_L FD_WDATA_L FD_DRATE0 FD_WGATE_L FD_INDEX_L FD_TRK0_L FD_MTR0_L FD_MSEN0 FD_WPROT_L FD_DR1_L FD_RDATA_L FD_DR0_L FD_HDSEL_L FD_MTR1_L FD_MSEN1 FD_DSKCHG_L...

  • Page 133: Front Panel Connector

    Front Panel Connector A 30-pin connector attaches to the chassis front panel containing reset, NMI, sleep, and power control switches, LED indicators, and IPMB connection. OM08031 Table 37. Front Panel Connector Pinout Signal Signal SPEAKER_OUT PWR_CNTRL_FP_L FP_ISOL CHASSIS_INTRUSION FP_HD_ACT_L FAN_TACH(0) FAN_TACH(1) SLEEP_CNTRL_l FAN_TACH(2)

  • Page 134: Smm Connector

    SMM Connector OM08032 Table 38. Server Management Module Connector Pinout Signal Description CPU_SMI_L System Management Interrupt LOCAL_I2C_SCL IPMB clock line Ground Reserved PWR_CNTRL_SFC_L Host power supply on/off control LOCAL_I2C_SDA IPMB serial data line 5VSTNDBY +5V standby indication (power OK) KEYLOCK_SFC_L Keyboard lock signal CPU_NMI Nonmaskable interrupt indication...

  • Page 135: Ipmb Connector

    IPMB Connector OM08035 Table 39. IPMB Connector Pinout Signal LOCAL_I2C_SCL LOCAL_I2C_SDA VGA Video Port OM04417 Table 40. Video Port Connector Pinout Signal Signal Green Blue DDCDAT HSYNC VSYNC DDCCLK...

  • Page 136: Keyboard And Mouse

    Keyboard and Mouse OM04418 The PS/2-compatible connectors share a common housing; they are functionally equivalent. Table 41. Keyboard and Mouse Connector Pinouts Keyboard signal Mouse signal KEYDAT MSEDAT FUSED_VCC (+5 V) FUSED_VCC (+5 V) KEYCLK MSECLK Parallel Port OM04416 Table 42. Parallel Port Connector Pinout Signal Signal...

  • Page 137: Serial Ports A And B

    Ring indication active Universal Serial Bus The InterServe 9000 provides a single, external USB connector at the back panel and an internal header to be used with device bay expansion. Table 44 lists the pinout for the USB external connector. Table 45 lists the pinout for the USB internal header.

  • Page 138: Narrow Scsi

    Narrow SCSI OM08028 Table 46. Narrow SCSI Connector Pinout Signal Signal TERMPWR SCD0_L RESERVED RESERVED SCD1_L SCD2_L SATN_L SCD3_L SCD4_L SBSY_L SCD5_L SACK_L SCD6_L SRESET_L SCD7_L SMSG_L SCDP_L SSEL_L SCD_L RESERVED SREQ_L RESERVED SIO_L...

  • Page 139: Wide Scsi Connector

    Wide SCSI Connector OM08027 Table 47. Wide SCSI Connector Pinout Signal Signal 1-16 49-50 TERMPWR TERMPWR TERMPWR TERMPWR Reserved Reserved 20-34 DB12_L ATN_L DB13_L DB14_L BSY_L DB15_L ACK_L DBP1_L RST_L DB0_L MSG_L DB1_L SEL_L DB2_L C/D_L DB3_L REQ_L DB4_L I/O_L DB5_L DB8_L DB6_L...

  • Page 140: Ide Connector

    IDE Connector OM08029 Table 48. IDE Connector Pinout Signal Signal RESET_L IDEDRQ DIOW_L DIOR_L IORDY DD10 CSEL (1 K p/d) IDEDAK_L DD11 IDEIRQ DD12 Reserved (N/C) IDESA1 DD13 PDIAG_L (tied to GND) IDESA0 DD14 IDESA2 IDECS1_L DD15 IDECS3_L IDEHDACT_L Keyed If no IDE drives are present, no IDE cable should be connected.

  • Page 141: Isa Connector

    ISA Connector Table 50. ISA Connector Pinout Signal Signal Signal Signal IOCHK_L DACK2_L RESET BALE IRQ9 DRQ2 -12V Connector key Connector key SRDY_L SBHE_L MEMCS16_L +12V LA23 IOCS16_L IOCHRDY LA22 IRQ10 SMEMW_L LA21 IRQ11 SA19 SMEMR_L LA20 IRQ12 SA18 IOW_L LA19 IRQ15 SA17...

  • Page 142: Pci Connector

    PCI Connector Table 51. PCI Connector Pinout Signal Signal Signal Signal TRST_L -12 V AD16 AD17 +12 V +3.3 V * C/BE2_L FRAME_L TD0 (NC) IRDY_L +5 V +5 V TRDY_L +3.3 V * INTA_L +5 V DEVSEL_L INTC_L INTB_L STOP_L +5 V INTD_L...

  • Page 143: Baseboard Jumpers

    Baseboard Jumpers One 11-pin single inline header provides three 3-pin jumper blocks that control various configuration options. Figure 44 shows the location. Items in bold in Table 52 show default placement for each configurable option. J6J1 OM08006 Figure 44. Baseboard Jumpers Table 52.

  • Page 144: General Procedure To Change Jumper Setting

    General Procedure to Change Jumper Setting The short general procedure for changing a configuration setting is the same for most of the jumper functions: 1. Observe the safety and ESD precautions at the beginning of Chapter 5 (page 81). 2. Turn off all connected peripherals, turn off system power, and disconnect all AC power cords. 3.

  • Page 145: Password Clear Jumper

    Password Clear Jumper The jumper at pins 5, 6, and 7 controls whether a stored password is retained or cleared during a system reset. The following procedure clears the current password and then enters a new one: 1. See “General Procedure to Change Jumper Setting” on page 144. 2.

  • Page 146: System I/O Addresses

    System I/O Addresses The following table shows the location in I/O space of all directly I/O-accessible registers. Table 53. System I/O Addresses Address(es) Resource Device Notes 0000h - 000Fh DMA Controller 1 PIIX4E 0010h - 001Fh DMA Controller 1 PIIX4E Aliased from 0000h - 000Fh 0020h - 0021h Interrupt Controller 1...
  • Page 147 continued Table 53. System I/O Addresses (continued) Address(es) Resource Device Notes 0077h RTC Data PIIX4E Aliased from 0071h 0080h - 008Fh DMA Low Page Register PIIX4E 0090h - 0091h DMA Low Page Register (aliased) PIIX4E 0092h System Control Port A (PC-AT PIIX4E control Port) (this port not aliased in DMA range)

  • Page 148: Memory Map Addresses

    continued Table 53. System I/O Addresses (continued) Address(es) Resource Device Notes 03C0h - 03CFh Video Display Controller 03D4h - 03DAh Color Graphics Controller 03E8h - 03EFh Serial Port A 03F0h - 03F5h Diskette Controller 03F6h - 03F7h Primary IDE - Sec. Diskette 03F8h - 03FFh Serial Port A (Primary) 0400h - 043Fh...

  • Page 149: Interrupts

    Interrupts The table below recommends the logical interrupt mapping of interrupt sources; it reflects a typical configuration, but these interrupts can be changed by the user. Use the information to determine how to program each interrupt. The actual interrupt map is defined using configuration registers in the PIIX4E and the I/O controller.

  • Page 150: Video Modes

    Video Modes The CL-GD5480 integrated video controller provides all standard IBM VGA modes. With 2 MB of synchronous graphics RAM (SGRAM) standard, the system supports special Cirrus Logic extended modes. Table 56 and Table 57 list the standard and extended modes that this implementation supports, including the number of colors and palette size (for example, 16 colors out of 256 K colors), resolution, pixel frequency, and scan frequencies.
  • Page 151 Table 57. Extended VGA Modes Mode(s) Bits per Pixel Freq. Horiz. Vert. Freq. in Hex pixel Colors Resolution (MHz) Freq. (KHz) (Hz) Memory 58, 6A 16/256K 800 X 600 35.2 58, 6A 16/256K 800 X 600 37.8 58, 6A 16/256K 800 X 600 48.1 58, 6A...
  • Page 152 Table 57. Extended VGA Modes (continued) Mode(s) Bits per Pixel Freq. Horiz. Vert. Freq. in Hex pixel Colors Resolution (MHz) Freq. (KHz) (Hz) Memory 800 X 600 68.2 63.6 640 X 480 31.5 640 X 480 31.5 37.9 640 X 480 31.5 37.5 640 X 480...
  • Page 153 Table 57. Extended VGA Modes (continued) Mode(s) Bits per Pixel Freq. Horiz. Freq. Vert. Freq. in Hex pixel Colors Resolution (MHz) (KHz) (Hz) Memory 1024 X 768 44.9 35.5 (interlaced) 1024 X 768 48.3 1024 X 768 1024 X 768 78.7 1024 X 768 94.5...

  • Page 155: A Equipment Log And Worksheets

    A Equipment Log and Worksheets Equipment Log Use the blank equipment log provided here to record information about your system. You will need some of this information when you run the SSU. Item Manufacturer Name and Model Serial Number Date Installed Number System Baseboard...
  • Page 156 Equipment Log (continued) Item Manufacturer Name and Model Serial Number Date Installed Number...

  • Page 157: Configuration Worksheets

    Configuration Worksheets The rest of this chapter consists of worksheets to record the settings you make when configuring the system using the SSU, BIOS Setup, and the Symbios SCSI Utility. If default values ever need to be restored to CMOS (for example, after a CMOS-clear), you must reconfigure the system. Referring to the filled-in worksheets could make your task easier.

  • Page 158: Ssu Worksheets

    Worksheet, Total Combined Power Used by the System 1. From the previous worksheet, enter the total current for each column. 2. Multiply the voltage by the total current to get the total wattage for each voltage level. 3. Add the total wattage for each voltage level to arrive at a total combined power usage on the power supply.
  • Page 159 ISA Board Definition If you have an ISA board with no .CFG file, you can define the board by using the SSU. It is necessary to define an ISA board only when you want to prevent other boards in the system from using the same IRQ levels, DMA channels, I/O Port addresses, or Memory addresses that your ISA board uses.
  • Page 160 Baseboard (SSU, Change Configuration Settings) Worksheet 5. Systems Group System Identification and Version Information SSU Configuration File Version MP Spec. Version 1.1 / 1.4 Processor Speed Setting Worksheet 6. Memory Subsystem Group Onboard Disk Controllers Onboard Communication Devices Enable / Disable Worksheet 7.
  • Page 161 Worksheet 10. IDE Subsystem Group IDE Configuration (drive name) Primary Master None / User / Auto / CD IDE Drive Options 2 Sector/Block / 4 Sector/Block 8 Sector/Block / 16 Sector/Block / Disable Primary Master Transfer Mode PIO 1 / PIO 2 / PIO 3 / PIO 4 Primary Master IDE Configuration (drive name)
  • Page 162 Worksheet 14. Security Subsystems Administrative Password Disable / Enable User Password Disable / Enable Secure Mode Hot-Key None / Ctrl-Alt-{ Lockout Timer Disable / { } minutes Secure Boot Mode Disable / Enable Video Blanking Disable / Enable Diskette Writes Disable / Enable Reset/Power Switch Locking Disable / Enable...
  • Page 163 Management Subsystem, System Sensor Control Worksheet For each sensor control, the display includes the choices shown below, with blanks for entering values. Write in both the sensor control and the values you select. This worksheet (two pages) provides space for a number of sensor controls; if you need more space, copy these pages to extend your worksheet.
  • Page 164 Item: Item: Disable / Enable Disable / Enable Upper Fatal: Upper Fatal: Upper Upper Warning: Warning: Lower Lower Warning: Warning: Lower Fatal: Lower Fatal: Item: Item: Disable / Enable Disable / Enable Upper Fatal: Upper Fatal: Upper Upper Warning: Warning: Lower Lower Warning:...
  • Page 165 Worksheet 18. Primary Master and Slave Submenu Type Auto / None / CD-ROM / IDE Removable ATAPI Removable / User Cylinders Heads Sectors Maximum Capacity Multi-Sector Transfer Disabled / 2 / 4 / 8 / 16 LBA Mode Control Disabled / Enabled 32 Bit I/O Disabled / Enabled Transfer Mode...
  • Page 166 Worksheet 23. I/O Device Configuration Submenu Serial Port A Disabled / Enabled / Auto / OS Controlled Base I/O Address 3F8h / 2F8h / 3E8h / 2E8h Interrupt 4 / 3 Serial Port B Disabled / Enabled / Auto / OS Controlled Mode Normal / IrDA / ASK-IR Base I/O Address...
  • Page 167 Worksheet 26. Server Menu. Processor Retest No / Yes Worksheet 27. System Management Submenu. Server Management Mode Disabled / Enabled System Event Logging Disabled / Enabled Clear Event Log Disabled / Enabled Assert NMI on AERR Disabled / Enabled Assert NMI on BERR Interrupt Routing Disabled / Enabled Assert NMI on PERR Interrupt Routing Disabled / Enabled...
  • Page 168 blank page...

  • Page 169: B Regulatory Specifications

    (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For questions related to electromagnetic compatibility performance of this product, contact: Intergraph Computer Systems Compliance Engineering Huntsville AL 35894-001...

  • Page 171: C Warnings

    C Warnings WARNING: English (US) AVERTISSEMENT: Français WARNUNG: Deutsch AVVERTENZA: Italiano ADVERTENCIAS: Español...

  • Page 172: Warning: English (Us)

    WARNING: English (US) The power supply in this product contains no user-serviceable parts. There may be more than one supply in this product. Refer servicing only to qualified personnel. Do not attempt to modify or use the supplied AC power cord if it is not the exact type required.
  • Page 173 WARNING: English (continued) A microprocessor and heat sink may be hot if the system has been run ning. Also, there may be sharp pins and edges on some board and chassis parts. Contact should be made with care. Consider wearing protective gloves. Danger of explosion if the battery is incorrectly replaced.

  • Page 174: Avertissement: Français

    AVERTISSEMENT: Français Le bloc d'alimentation de ce produit ne contient aucune pièce pouvant être réparée par l'utilisateur. Ce produit peut contenir plus d'un bloc d'alimentation. Veuillez contacter un technicien qualifié en cas de problème. Ne pas essayer d'utiliser ni modifier le câble d'alimentation CA fourni, s'il ne correspond pas exactement au type requis.
  • Page 175 AVERTISSEMENT: Français (suite) Le microprocesseur et le dissipateur de chaleur peuvent être chauds si le système a été sous tension. Faites également attention aux broches aiguës des cartes et aux bords tranchants du capot. Nous vous recommandons l'usage de gants de protection. Danger d'explosion si la batterie n'est pas remontée correctement.

  • Page 176: Warnung: Deutsch

    WARNUNG: Deutsch Benutzer können am Netzgerät dieses Produkts keine Reparaturen vornehmen. Das Produkt enthält möglicherweise mehrere Netzgeräte. Wartungsarbeiten müssen von qualifizierten Technikern ausgeführt werden. Versuchen Sie nicht, das mitgelieferte Netzkabel zu ändern oder zu verwenden, wenn es sich nicht genau um den erforderlichen Typ handelt. Ein Produkt mit mehreren Netzgeräten hat für jedes Netzgerät ein eigenes Netzkabel.
  • Page 177 WARNUNG: Deutsch (fortsetzung) Der Mikroprozessor und der Kühler sind möglicherweise erhitzt, wenn das System in Betrieb ist. Außerdem können einige Platinen und Gehäuseteile scharfe Spitzen und Kanten aufweisen. Arbeiten an Platinen und Gehäuse sollten vorsichtig ausgeführt werden. Sie sollten Schutzhandschuhe tragen. Bei falschem Einsetzen einer neuen Batterie besteht Explosionsgefahr.

  • Page 178: Avvertenza: Italiano

    AVVERTENZA: Italiano Rivolgersi ad un tecnico specializzato per la riparazione dei componenti dell’alimentazione di questo prodotto. È possibile che il prodotto disponga di più fonti di alimentazione. Non modificare o utilizzare il cavo di alimentazione in c.a. fornito dal produttore, se non corrisponde esattamente al tipo richiesto.
  • Page 179 AVVERTENZA: Italiano (continua) Se il sistema è stato a lungo in funzione, il microprocessore e il dissipatore di calore potrebbero essere surriscaldati. Fare attenzione alla presenza di piedini appuntiti e parti taglienti sulle schede e sul telaio. È consigliabile l'uso di guanti di protezione. Esiste il pericolo di un esplosione se la pila non viene sostituita in modo corretto.

  • Page 180: Advertencias: Español

    ADVERTENCIAS: Español El usuario debe abstenerse de manipular los componentes de la fuente de alimentación de este producto, cuya reparación debe dejarse exclusivamente en manos de personal técnico especializado. Puede que este producto disponga de más de una fuente de alimentación.
  • Page 181 ADVERTENCIAS: Español (continúa) Si el sistema ha estado en funcionamiento, el microprocesador y el disipador de calor pueden estar aún calientes. También conviene tener en cuenta que en el chasis o en el tablero puede haber piezas cortantes o punzantes. Por ello, se recomienda precaución y el uso de guantes protectores.
  • Page 182 Blank page...

  • Page 183: Index

    Index recovery boot settings, jumper, 145 removing, 104 AC input serial ports, 137 power connector, 14 Server Management Module connector, access cover installing, 84 video port connector, 135 removing, 83 battery add-in board disposing of safely, 113 expansion slot cover, 12, 14, 86, 87 installing, 114 installing, 86 removing, 113...
  • Page 184 DIMMs, use extreme care when Console Redirection submenu, configuring in installing, 108 Setup, 42 do not use hard drives in external bays, controller baseboard management (BMC), 26 ESD protection, 68, 73, 82, 104 diskette (floppy), 26 installing chassis covers for cooling and IDE, 26 airflow, 82, 104 keyboard/mouse, 26...
  • Page 185 cable requirements, 91 grounding clip, removable media drives, diskette, 12 hot-swapping SCSI hard disk drives, 73 diskette media supported, 16 limit use of 5.25-inch hard drives, 92 expansion bays, 12 fans on high-power SCSI hard drives, Exit menu, configuring, Setup, 43 expanded video memory, 25 hard disk, 12 expansion slot...
  • Page 186 FRUSDR load utility, 31, 64 firmware update, 70 when to run, 64, 68 installing termination board, 111 internal bay size and capacity, 16 interrupt gasket, EMI protection at I/O connectors, 105 mapping, 149 grounding clip, removable media drives, 93 must disconnect IDE cable to reuse interrupt, 91 intrusion detection, 26, 27 IPMB for monitoring status, 26...
  • Page 187 connector, 131 using to reactivate keyboard/mouse, 26, memory, 22 which type to set, 28 addresses, 23 amount installed, 19 connectors on baseboard, 142 amount tested, POST, 32 embedded devices, 19 as used by different operating systems, expansion slots, 19 base amount, 23 feature summary, 24 capacity, 19 installing add-in board, 86...
  • Page 188 monitoring power state, 26 removing foam covers, 96 worksheet, calculating DC power, 157 removing termination board, 111 problems reset button, 13 after running new application software, reset system, 31, 115 RTC, See real-time clock after system has been running correctly, application software, 122 beep codes, 119 S.E.C cartridge...
  • Page 189 unattended start, 30 worksheet, boot hard drive, 167 using hot key combination, 31 worksheet, boot menu, 167 video blanking, 29 worksheet, I/O Device Configuration submenu, 166 Security menu worksheet, keyboard features submenu, configuring, Setup, 40 serial port worksheet, main menu, 164 connectors on baseboard, 137 worksheet, primary master and slave connectors, back panel, 14...
  • Page 190 SCI files, 45 software locking feature, 28 when to run, 44 extended modes, 151 worksheet, add/remove board, 158 monitor connector, 135 worksheet, change baseboard standard modes, 150 configuration, 160 video worksheet, define ISA board, 159 blanking for security, 29 worksheet, management subsystem, 163 controller, 25 worksheet, system sensor control, 163 expansion, 25...
  • Page 191 Primary Master and Slave submenu, server menu, Setup, 167 Setup, 165 system management submenu, Setup, 167 Security menu, Setup, 166 system sensor control, SSU, 163 server console redirection, Setup, 167 write to diskette, disabling, 29...

Table of Contents
