Closing the Base Unit

CAUTION

After servicing or upgrading the system, always replace the panels that were removed. The

panels ensure the system maintains proper air flow, so internal components do not overheat

and fail. The covers also ensure that electromagnetic interference (EMI) emissions remain

below the standard requirements. The system will not start unless the panels are properly

replaced.

To close the base unit:

1. Disconnect the antistatic wrist strap from the base unit.

2. Replace the side panels and turn the twist locks clockwise to lock the panels into place.

3. If the unit is rack-mounted:

Unlock the sliding shelf by pressing the release tab.

Push the base unit into the rack until it fully retracts and locks into place.

Secure the sliding shelf by installing the screw under the sliding shelf handle.
