Eq (Equalizer) - Boss GT-10 Owner's Manual

Parameter/ Explanation
Range
CUSTOM SPEAKER SETTING
Setting available when SP Type is set to Custom.
SP Size (Speaker Size)
5"–15" Selects the size of speaker.
Color Low
Adjusts the speaker section's low-fre-
-10–+10
quency tone.
ColorHigh
Adjusts the speaker section's high-fre-
-10–+10
quency tone.
SP Number (Speaker Number)
x1, x2, x4, x8 Sets the number of speakers.
Cabinet
Selects the speaker cabinet type.
Open This is an open-backed cabinet.
This type of cabinet features an enclosed
Close
rear panel.
Chapter 8 Parameters Guide

EQ (Equalizer)

This adjusts the tone as a equalizer. A parametric type is
adopted for the high-middle and low-middle range.
Parameter/ Explanation
Range
EQ ON/OFF (Equalizer ON/OFF)
Turns the EQ effect on/off.
Off, On
Pressing [EQ] switches On and Off.
Low Cut (Low Cut Filter)
This sets the frequency at which the low cut fil-
Flat,
ter begins to take effect. When "Flat" is selected,
55Hz–800Hz
the low cut filter will have no effect.
Low Gain
-20–+20dB Adjusts the low frequency range tone.
Lo-Mid f (Low Middle Frequency)
20Hz– Specifies the center of the frequency range that
10.0kHz will be adjusted by the Lo-Mid G.
Lo-Mid Q (Low Middle Q)
Adjusts the width of the area affected by the EQ
0.5–16 centered at the LO-Mid f.
Higher values will narrow the area.
Lo-Mid G (Low Middle Gain)
-20–+20dB Adjusts the low-middle frequency range tone.
Hi-Mid f (High Middle Frequency)
20Hz– Specifies the center of the frequency range that
10.0kHz will be adjusted by the Hi-Mid G.
Hi-Mid Q (High Middle Q)
Adjusts the width of the area affected by the EQ
0.5–16 centered at the Hi-Mid f.
Higher values will narrow the area.
Hi-Mid G (High Middle Gain)
-20–+20dB Adjusts the high-middle frequency range tone.
High Gain
-20–+20dB Adjusts the high frequency range tone.
High Cut (High Cut Filter)
This sets the frequency at which the high cut fil-
700Hz–
ter begins to take effect. When "Flat" is selected,
11kHz, Flat
the high cut filter will have no effect.
Level
Adjusts the overall volume level of the equaliz-
-20–+20dB
er.
