1. FUNCTIONS AND CONFIGURATION
(b) For 1-phase 100V to 120VAC
(Note 2)
Power supply
Circuit breaker
(NFB) or fuse
Magnetic
contactor
(MC)
Power
factor
improving
L
reactor
L
(FR-BAL)
Control circuit terminal block
L
21
L
11
Regenerative option
Note 1. The HC-SFS, HC-RFS, HC-UFS 2000 r/min series have cannon connectors.
2. Refer to section 1.2 for the power supply specification.
Options and auxiliary equipment
Circuit breaker
Magnetic contactor
MR Configurator
(Servo configuration software)
Regenerative option
Servo amplifier
CHARGE
To CN2
1
U V
2
D
P
C
Reference
Section 14.2.2
Section 14.2.2
Chapter 6
Section 14.1.1
To CN1A
To CN1B
To CN3
W
Protective earth (PE) terminal
1 - 22
Options and auxiliary equipment
Cables
Manual pulse generator
External digital display
Power factor improving reactor Section 14.2.3
Command device
Junction terminal block
Manual pulse generator
External digital display
MR Configurator
(Servo configuration
Personal
software
computer
MRZJW3-SETUP151E)
(Note 1)
Encoder cable
(Note 1)
Power supply lead
Servo motor
Reference
Section 14.2.1
Section 14.1.8
Section 14.1.7
