60 C 4: B
HAPTER ASIC
Configuring a
CSU/DSU Interface
for Multiple Path,
Channelized Service
C P , P
ONFIGURATION OF ORTS
For E1 lines, only short haul is supported. Use SH7 for E1 lines.
LH1 T1 0 dB
LH2 T1 7.5 dB
LH3 T1 15 dB
LH4 T1 22.5 dB
SH1 T1 0-133 feet
SH2 T1 133-266 feet
SH3 T1 266-399 feet
SH4 T1 399-533 feet
SH5 T1 533-655 feet
SH7 E1 G.703 120 Ohm
5 Enable the connector, using:
SETDefault !<path> -PAth ConnControl = Enabled
Connector parameter settings are not applied until the connector is
enabled.
This section describes how to configure Ultra-WAN CSU/DSU interface for
multiple path, channelized service.
To configure the Ultra-WAN CSU/DSU interface, follow these steps:
1 Set the FrameMode as appropriate for your setup:
SETDefault !<path> -PAth FrameMode = T1_SF | T1_ESF | E1_CRC4 |
E1_NOCRC
where <path> = 4A, 4B, 4C, or 4D.
The FrameMode parameter allows you to specify the frame mode. The
allowable values are the following:
T1_SF Superframe format T1.
T1_ESF Extended Superframe format T1.
E1_CRC4 CRC-active E1.
E1_NOCRC E1 without an active CRC.
2 Set the connector type as appropriate for your setup using:
SETDefault !<path> -PAth CONNector = E1_Channelized
|T1_Channelized
where <path> = 4A, 4B, 4C, or 4D.
, C
ATHS AND ONNECTORS
