130 A E: T
PPENDIX ROUBLESHOOTING
3 Select Dump Configuration Menu from the System Configuration menu.
The default parameters are shown in bold:
1. Port Selection
2. Baud Rate
3. Duplex Mode
4. Dump Destination
4 Select Dump Destination.
The following options are available:
1. No Full Dump
2. Network
5 If you select No Full Dump, the system performs a partial dump to the
FPROM. You do not have to complete the rest of this procedure.
6 If you want a full dump to the network, select Network.
The following options must be configured for Network:
1. Client
2. Server
3. Gateway
4. Remote File Server (not applicable)
5. Subnet Mask
6. Dump Destination Directory
7 Set the IP addresses for the client, server, gateway, and subnet mask.
a Select Client and enter the IP address associated with the Ethernet
port of the PathBuilder switch.
b Return to the Dump Destination menu and select Server and enter the
IP address associated with the TFTP server.
c If necessary, select Gateway from the Dump Destination menu and
enter the IP address of the default gateway leading to the network on
which the TFTP server resides.
d If subnet masks are in use, select Subnet Mask from the Dump
Destination menu and enter the subnet mask associated with the IP
network attached to the Ethernet port.
8 Select Dump Destination Directory on the Dump Destination menu to
configure the location on the TFTP server to which the dump file will go.
The default destination is /dump.
9 Enter the target directory on the TFTP server.
LAN1
Auto Baud
Auto Duplex
No Full Dump
