# SETDefault !E1CHAN4A -PAth ChannelBaud = CB56K
# Enable paths
SETDefault !4A.1-!4D.31 -PAth CONTrol = Enable
Example 10.
########################################################################
########################################################################
# ULTRAWAN CONNECTOR CONFIGURATION FILE
# T1 LEASED, SINGLE PATH TEMPLATE
# HOW TO CONFIGURE MULTIPLE CONNECTORS SIMULTANEOUSLY
# This example shows how to configure connectors 4A, 4B, 4C, and 4D
# simultaneously by creating groups of connectors via the
# Instance Group command. To specify which connectors are
# included in this grouping, just add or delete the according references
# in the Instance Group command.
# 4A and 4C, the command would look like the following:
# Add -SYS InstanceGRoup T1FAT "!4A, !4C" PAth
# Add Instance Groups to cover all 4 UltraWAN connectors and paths
###### Note: T1FAT is short for T1, LEased, FAT (one) channel
Add -SYS InstanceGRoup T1FAT
Add -SYS InstanceGRoup T1FATPA "!4A.1, !4B.1, !4C.1, !4D.1" PAth
# Connector-level path parameter configuration
# The following parameter settings are only typical example settings.
# Your network-specific settings need to be assigned by consulting the
# connector-level path parameter documentation in the document
# "Using the PathBuilder Switch"
SETDefault !T1FAT -PAth FrameMode
SETDefault !T1FAT -PAth CONNector
SETDefault !T1FAT -PAth LineCoding
SETDefault !T1FAT -PAth LineDistance = LH1
SETDefault !T1FAT -PAth CLock
# Path-level path parameter configuration
# The following parameters may need to be changed from their default
# settings, based on your specific environment topology:
#
# ChannelMap: This parameter specifies the timeslots (i.e. channels)
# associated with the specified path.
# for path 4A.1 to map to all 24 timeslots (1 through 24)
# on connector 4A, 4B.1 to map to all 24 timeslots on
# connector 4B, etc.
# If all timeslots will not be used, this parameter setting
# will need to be changed via the DELete command, as
For example, to include only connectors
"!4A, !4B, !4C,
= T1_ESF
= T1_Unstructured
= B8ZS
= External
Example Configuration Templates
!4D" PAth
Default setting is
