WanCounters

Syntax
Description
CONNECTOR 4B
TIME SINCE FLUSH/REBOOT (days:hours:mins:secs):
------------------------------------------------------------------------------
CUMULATIVE STATISTICS SINCE LAST FLUSHED OR REBOOTED+
ES 00001
SES 00019K
UAS 00005
BES 00010
CSS 00020
LOFC 00010
EFS 00245M
------------------------------------------------------------------------------
LAST 24 HOURS STATISTICS IN 15 MINUTE SAMPLES
00:15 00:30
ES 00000 00000
SES 00000 00000
UAS 00900 00900
BES 00900 00900
CSS 00000 00000
LOFC 00000 00000
EFS 00000 00000
------------------------------------------------------------------------------
Before changes to this parameter can take effect a "SETDefault !<path>
-PATH ConnControl=Enable" command needs to be issued on the
corresponding connector.
SHow [!<path>] -PAth WanCounters
The WanCounters parameter displays statistics conforming to AT&T
TR54016. Although these statistics are tailored to T1 ESF lines, they can
also be used to monitor status on other types of T1 lines, and E1 lines as
well. The statistics are collected in 96 sample intervals (15 min samples
over the last 24 hour period) and are collected for each T1/E1 connector.
A partial sample display is shown here:
00:45 01:00 01:15
00000 00000 00000
00000 00000 00000
00900 00900 00900
00900 00900 00900
00000 00000 00000
00000 00000 00000
00000 00000 00000
The statistics definitions are as follows:
ES - Errored Second = A second in which a OOF (Out of Frame) or CRC
(Cyclic Redundancy Check error) occured and a UAS has not occured.
SES - Severely Errored Second = A second in which a OOF or greater
than 319 CRCs occured and a UAS(see below) has not occured.
UAS - UnAvailable Second = A second in which all of the previous 10
contiguous one-seconds were all SES, or in which any of the previous
00:02:34:12
01:30 01:45 02:00
00000 00000 00000
00000 00000 00000
00900 00900 00900
00900 00900 00900
00000 00000 00000
00000 00000 00000
00000 00000 00000
02:15
00000
00000
00900
00900
00000
00000
00000
175
