SETDefault !T1PRI -PAth FrameMode
SETDefault !T1PRI -PAth CONNector
SETDefault !T1PRI -PAth SwitchType
SETDefault !T1PRI -PAth LineCoding
SETDefault !T1PRI -PAth LineDistance = LH1
SETDefault !T1PRI -PAth CLock
# Enable Connectors
SETDefault !T1PRI -PAth ConnControl = Enable
# Add Instance Group to cover all paths on each UltraWAN connector:
###### Note: T1PRI4x is short for T1, PRI dial, all paths on 4x
Add -SYS InstanceGroup T1PRI4A "!4A.1 - !4A.23" PAth
Add -SYS InstanceGroup T1PRI4B "!4B.1 - !4B.23" PAth
Add -SYS InstanceGroup T1PRI4C "!4C.1 - !4C.23" PAth
Add -SYS InstanceGroup T1PRI4D "!4D.1 - !4D.23" PAth
# Path-level path parameter configuration
# The following parameters may need to be changed from their default
# settings, based on your specific environment topology:
#
# LocalDialNo:
#
#
#
# Rate Adaption:
#
#
#
#
#
# Some examples on changing these parameter settings are:
#
# SETDefault !T1PRI4A -PAth LocalDialNo = "4085551212"
# SETDefault !T1PRI4B -PAth LocalDialNo = "4085555555"
#
# SETDefault !T1PRI4A -PAth RateAdaption = "Rate56"
# SETDefault !T1PRI4B -PAth RateAdaption = "Rate56"
>Example 12.
########################################################################
########################################################################
# ULTRAWAN CONNECTOR CONFIGURATION FILE
# T1 LEASED, CHANNELIZED TEMPLATE
# HOW TO CONFIGURE MULTIPLE CONNECTORS SIMULTANEOUSLY
# This example shows how to configure connectors 4A, 4B, 4C, and 4D
= T1_ESF
= T1_PRI
= ATT5ESS
= B8ZS
= External
If you want outbound calls to provide a calling
phone number, you will need to set this parameter
for each path that will support outbound calls.
There is no default setting for this parameter.
If you want outbound calls using a given path to
attempt connection only at one rate (56K or 64K),
but not both, then this parameter will need to be
changed from the default setting of AUTO (which,
if necessary, attempts both) to Rate56K, or Rate64K.
