Add -SYS InstanceGroup T1CHAN20 "!4A.20, !4B.20, !4C.20, !4D.20" PAth
Add -SYS InstanceGroup T1CHAN21 "!4A.21, !4B.21, !4C.21, !4D.21" PAth
Add -SYS InstanceGroup T1CHAN22 "!4A.22, !4B.22, !4C.22, !4D.22" PAth
Add -SYS InstanceGroup T1CHAN23 "!4A.23, !4B.23, !4C.23, !4D.23" PAth
Add -SYS InstanceGroup T1CHAN24 "!4A.24, !4B.24, !4C.24, !4D.24" PAth
# Add Instance Group to cover all paths on each UltraWAN connector:
###### Note: T1CHAN4x is short for T1, leased, CHANnelized, all paths on 4x
Add -SYS InstanceGroup T1CHAN4A "!4A.1 - !4A.24" PAth
Add -SYS InstanceGroup T1CHAN4B "!4B.1 - !4B.24" PAth
Add -SYS InstanceGroup T1CHAN4C "!4C.1 - !4C.24" PAth
Add -SYS InstanceGroup T1CHAN4D "!4D.1 - !4D.24" PAth
# Path-level path parameter configuration
# The following parameters may need to be changed from their default
# settings, based on your specific environment topology:
#
# ChannelMap: This parameter specifies the timeslots (i.e. channels)
# associated with each specific path.
# no timeslots assigned so that deletions are not required.
# Most likely, the timeslots mapping needs to differ from
# this default setting.
# below will allocate the timeslots on a one-to-one
# basis with each of the 24 paths.
ADD !T1CHAN1 -PA ChannelMap
ADD !T1CHAN2 -PA ChannelMap
ADD !T1CHAN3 -PA ChannelMap
ADD !T1CHAN4 -PA ChannelMap
ADD !T1CHAN5 -PA ChannelMap
ADD !T1CHAN6 -PA ChannelMap
ADD !T1CHAN7 -PA ChannelMap
ADD !T1CHAN8 -PA ChannelMap
ADD !T1CHAN9 -PA ChannelMap
ADD !T1CHAN10 -PA ChannelMap 10
ADD !T1CHAN11 -PA ChannelMap 11
ADD !T1CHAN12 -PA ChannelMap 12
ADD !T1CHAN13 -PA ChannelMap 13
ADD !T1CHAN14 -PA ChannelMap 14
ADD !T1CHAN15 -PA ChannelMap 15
ADD !T1CHAN16 -PA ChannelMap 16
ADD !T1CHAN17 -PA ChannelMap 17
ADD !T1CHAN18 -PA ChannelMap 18
ADD !T1CHAN19 -PA ChannelMap 19
ADD !T1CHAN20 -PA ChannelMap 20
ADD !T1CHAN21 -PA ChannelMap 21
ADD !T1CHAN22 -PA ChannelMap 22
The sequence of commands given
1
2
3
4
5
6
7
8
9
Example Configuration Templates
Default setting is
