150 A G: C
PPENDIX OMPLETING
# Enable Connector
SETDefault !4A -PAth ConnControl = Enable
Example 6.
########################################################################
########################################################################
# ULTRAWAN CONNECTOR CONFIGURATION FILE
# T1 LEASED, CHANNELIZED TEMPLATE
# HOW TO CONFIGURE A SINGLE CONNECTOR
# This example shows how to configure connector 4A. To configure
# connectors other than 4A, substitute the connector name.
# For example, to configure connector 4B, replace !4A with !4B
# Connector-level path parameter configuration
# The following parameter settings are only typical example settings.
# Your network-specific settings need to be assigned by consulting the
# connector-level path parameter documentation in the document
# "Using the PathBuilder Switch"
SETDefault !4A -PAth FrameMode
SETDefault !4A -PAth CONNector
SETDefault !4A -PAth LineCoding
SETDefault !4A -PAth LineDistance = LH1
SETDefault !4A -PAth CLock
# Path-level path parameter configuration
# The following parameters may need to be changed from their default
# settings, based on your specific environment topology:
#
# ChannelMap: This parameter specifies the timeslots (i.e. channels)
# associated with each specific path.
# no timeslots assigned so that deletions are not required.
# Most likely, the timeslots mapping needs to differ from
# this default setting.
# below will allocate the timeslots on a one-to-one
# basis with each of the 24 paths.
ADD !4A.1 -PA ChannelMap 1
ADD !4A.2 -PA ChannelMap 2
ADD !4A.3 -PA ChannelMap 3
ADD !4A.4 -PA ChannelMap 4
ADD !4A.5 -PA ChannelMap 5
ADD !4A.6 -PA ChannelMap 6
ADD !4A.7 -PA ChannelMap 7
ADD !4A.8 -PA ChannelMap 8
ADD !4A.9 -PA ChannelMap 9
ADD !4A.10 -PA ChannelMap 10
T U -WAN C
HE LTRA ONFIGURATION
= T1_ESF
= T1_Channelized
= B8ZS
= External
The sequence of commands given
Default setting is
