Path Parameters

ChannelBaud

Syntax
Default
Description
Values

ChannelMap

Syntax
Default
Description
Channel Number Values
SETDefault !<path> -PAth ChannelBaud = [ cb56k | cb64k ]
SHow !<path> -PAth ChannelBaud
SHowDefault !<path> -PAth ChannelBaud
cb64k
The ChannelBaud parameter specifies the baud rate (56kbits/sec or
64kbits/sec) of each timeslot (channel) mapped to the specified path. All
timeslots mapped to a given path must be equivalent in baudrate. This
parameter is only used on Ultra-WAN CSU/DSU connectors, and only in
non-dial configurations.
cb56k 56kbits/sec timeslot data throughput rate
cb64k 64kbits/sec timeslot data throughput rate
ADD !<path> -PAth ChannelMap <channel numbers, with commas>
DELete !<path> -PAth ChannelMap <channel numbers, with commas>
SHow !<path> -PAth ChannelMap
SHowDefault !<path> -PAth ChannelMap
Varies depending on connector values
E1_U,T1_U - All timeslots allocated to x.1 path
E1_C, T1_C - No timeslots allocated to any path, an add command must
be used to assign timeslots.
The ChannelMap parameter specifies the timeslots (channels) associated
with the specified path. All paths on an Ultra-WAN CSU/DSU connector,
except the first (4x.1), have a default assignment of no timeslots. The first
path (4x.1) has a factory-configured default assignment of all available
timeslots for that connector. This parameter is only used on Ultra-WAN
CSU/DSU connectors, and only in non-dial configurations.
1 through 31 for E1 CONNector settings.
1 through 24 for T1 CONNector settings.
Numbers separated by a comma: 1,2,3,4,5,6
Path Parameters 177
