Ultra-WAN connectors
3A 3B
Link
LAN 1
Active
Fault 100Mb
LAN 1 and LAN 2
Ethernet
connectors
Hardware Interrupt
Switch

Reset Button

Figure 8 Front Panel (model S599)
Carrier
Alarm
3C 3D Lpbk
Link
LAN 2
Active
Fault 100Mb
Console
connector
Link, Active, Fault,
and 100Mb LEDs
The hardware interrupt switch is located on the left side of the switch
(when facing the front panel). Press the switch with a nonconductive
object, such as a plastic stylus, to activate the monitor firmware utility.
Left side of unit

Hardware interrupt switch

WARNING: Use only a nonconductive object, such as a plastic stylus, to
press the hardware interrupt switch. Do not use the tip of a pencil.
Graphite particles from the pencil may cause you to receive an electric
shock and may damage components on the motherboard.
Pressing the Reset button resets the switch. The reset button is on the
front panel.
SYSTEM
Run
Console
Fwd
Reset Load
Status
Power
Test /Fault
Status
Fwd and
LEDs Power/
Fault LED
Reset
Run, Load,
and Test LEDs
Hardware Features
WAN
PathBuilder S500 Series
Carrier, Alarm,
and Lpbk LEDs
23
®
