Positioning A Phone Number; Editing An Existing Phone Number; Deleting A Phone Number - 3Com 3C8S5007 - SuperStack II PathBuilder S500 Switch User Manual

Positioning a Phone
Number
Editing an Existing
Phone Number
Deleting a Phone
Number
ADD !V1 -PORT DialNoList Ò123-4567aÓ
ADD !V1 -PORT DialNoList Ò123-4567bÓ
The bridge/router dials 123-4567 three times.
To insert a phone number into a specific position in the dial number
list, enter the Pos (Position) keyword with a nonzero number after the
dial string.
For example, to insert a phone number for port 4 into position 2 of the
dial number list that contains 10 phone numbers, enter:
ADD !4 -PORT DialNoList Ò510-555-7000Ó Pos = 2
The software inserts the new phone number into position 2. The phone
number that was previously in position 2 is now in position 3. If the
phone number already exists in the dial number list, it will be moved to
position 2. You also can include the Baud and Type keywords in any
order when inserting phone numbers into the dial number list.
You can change the position in the list, change the baud rate, and
change the device type. To change anthing else you must delete and
re-add the entry.
For example, if port 3 has already been assigned 612-345-3989 in
position 2 with a baud rate of 64 kbps, you can change the baud rate
by entering:
ADD !3 -PORT DialNoList Ò612-345-3989Ó Pos = 2 Baud = 14.4
Because the dial string is case-sensitive, make sure to match it exactly to
successfully edit an existing string when characters other than numbers
are used.
To remove a phone number from the dial number list, use:
DELete !<port> -PORT DialNoList Ò<phone no>Ó
The phone number is case-sensitive and must be matched exactly.
Working with Dial Number Lists 109
