144 A G: C
PPENDIX OMPLETING
Example
Configuration
Templates
Example 1.
########################################################################
########################################################################
# ULTRAWAN CONNECTOR CONFIGURATION FILE
# E1 LEASED, SINGLE PATH TEMPLATE
# HOW TO CONFIGURE A SINGLE CONNECTOR
# This example shows how to configure connector 4A. To configure
# connectors other than 4A, substitute the connector name.
# For example, to configure connector 4B, replace 4A with 4B
# in all of the commands shown below
# Connector-level path parameter configuration
# The following parameter settings are only typical example settings.
# Your network-specific settings need to be assigned by consulting the
# connector-level path parameter documentation in the document
# "Using the PathBuilder Switch"
SETDefault !4A -PAth FrameMode
SETDefault !4A -PAth CONNector
SETDefault !4A -PAth LineCoding
SETDefault !4A -PAth LineDistance = SH7
SETDefault !4A -PAth CLock
# Path-level path parameter configuration
# The following parameters may need to be changed from their default
# settings, based on your specific environment topology:
#
# ChannelMap: This parameter specifies the timeslots (i.e. channels)
# associated with the specified path.
# for path 4A.1 to map to all 31 timeslots (1 through 31).
# If all timeslots will not be used, this parameter setting
# will need to be changed via the DELete command, as
# shown below.
# back channels.
# ChannelBaud: This parameter specifies the baud rate (56K or 64K) of
# each timeslot (i.e. channel) mapped to the
# specified path.
# This setting can be changed to CB56K (56kbits/sec) for
# leased-line paths that require 56kbit/sec operation
#
# Some examples on changing these parameter settings are:
#
T U -WAN C
HE LTRA ONFIGURATION
= E1_CRC4
= E1_Unstructured
= HDB3
= External
Note that the ADD command is used to add
Default setting is CB64K (64kbits/sec).
Default setting is
