160 A G: C
PPENDIX OMPLETING
# simultaneously by creating groups of connectors and paths via the
# Instance Group command. To specify which connectors and paths are
# included in this grouping, just add or delete the according references
# in the Instance Group command.
# 4A and 4C, the commands would look like the following:
# Add -SYS InstanceGRoup T1CHAN "!4A, !4C" PAth
# Add -SYS InstanceGRoup T1CHAN1 "!4A.1, !4C.1" PAth
# Add Instance Groups to cover all 4 UltraWAN connectors
###### Note: T1CHAN is short for T1, leased, CHANnelized
Add -SYS InstanceGRoup T1CHAN "!4A, !4B, !4C, !4D" PAth
# Connector-level path parameter configuration
# The following parameter settings are only typical example settings.
# Your network-specific settings need to be assigned by consulting the
# connector-level path parameter documentation in the document
# "Using the PathBuilder Switch"
SETDefault !T1CHAN -PAth FrameMode
SETDefault !T1CHAN -PAth CONNector
SETDefault !T1CHAN -PAth LineCoding
SETDefault !T1CHAN -PAth LineDistance = LH1
SETDefault !T1CHAN -PAth CLock
# Enable Connectors
SETDefault !T1CHAN -PAth ConnControl
# Add Instance Groups to cover paths on all 4 UltraWAN connectors
###### Note: T1CHANx is short for T1, leased, CHANNelized, path #x
Add -SYS InstanceGroup T1CHAN1
Add -SYS InstanceGroup T1CHAN2
Add -SYS InstanceGroup T1CHAN3
Add -SYS InstanceGroup T1CHAN4
Add -SYS InstanceGroup T1CHAN5
Add -SYS InstanceGroup T1CHAN6
Add -SYS InstanceGroup T1CHAN7
Add -SYS InstanceGroup T1CHAN8
Add -SYS InstanceGroup T1CHAN9
Add -SYS InstanceGroup T1CHAN10 "!4A.10, !4B.10, !4C.10, !4D.10" PAth
Add -SYS InstanceGroup T1CHAN11 "!4A.11, !4B.11, !4C.11, !4D.11" PAth
Add -SYS InstanceGroup T1CHAN12 "!4A.12, !4B.12, !4C.12, !4D.12" PAth
Add -SYS InstanceGroup T1CHAN13 "!4A.13, !4B.13, !4C.13, !4D.13" PAth
Add -SYS InstanceGroup T1CHAN14 "!4A.14, !4B.14, !4C.14, !4D.14" PAth
Add -SYS InstanceGroup T1CHAN15 "!4A.15, !4B.15, !4C.15, !4D.15" PAth
Add -SYS InstanceGroup T1CHAN16 "!4A.16, !4B.16, !4C.16, !4D.16" PAth
Add -SYS InstanceGroup T1CHAN17 "!4A.17, !4B.17, !4C.17, !4D.17" PAth
Add -SYS InstanceGroup T1CHAN18 "!4A.18, !4B.18, !4C.18, !4D.18" PAth
Add -SYS InstanceGroup T1CHAN19 "!4A.19, !4B.19, !4C.19, !4D.19" PAth
T U -WAN C
HE LTRA ONFIGURATION
For example, to include only connectors
= T1_ESF
= T1_Channelized
= B8ZS
= External
= Enable
"!4A.1, !4B.1,
"!4A.2, !4B.2,
"!4A.3, !4B.3,
"!4A.4, !4B.4,
"!4A.5, !4B.5,
"!4A.6, !4B.6,
"!4A.7, !4B.7,
"!4A.8, !4B.8,
"!4A.9, !4B.9,
!4C.1, !4D.1 " PAth
!4C.2, !4D.2 " PAth
!4C.3, !4D.3 " PAth
!4C.4, !4D.4 " PAth
!4C.5, !4D.5 " PAth
!4C.6, !4D.6 " PAth
!4C.7, !4D.7 " PAth
!4C.8, !4D.8 " PAth
!4C.9, !4D.9 " PAth
