# DELete !4A.1 -PAth ChannelMap 1,2,3,7,12,30
# ADD !4A.1 -PAth ChannelMap 1,2,3,7,12,30
# SETDefault !4A.1 -PAth ChannelBaud = CB56K
# Enable Connector
SETDefault !4A -PAth ConnControl = Enable
Example 2.
########################################################################
########################################################################
# ULTRAWAN CONNECTOR CONFIGURATION FILE
# E1 PRI TEMPLATE
# HOW TO CONFIGURE A SINGLE CONNECTOR
# This example shows how to configure connector 4A. To configure
# connectors other than 4A, substitute the connector name, accordingly
# For example, to configure connector 4B, replace 4A with 4B
# in all of the commands shown below
# Connector-level path parameter configuration
# The following parameter settings are only typical example settings.
# Your network-specific settings need to be assigned by consulting the
# connector-level path parameter documentation in the document
# "Using the PathBuilder Switch"
SETDefault !4A -PAth FrameMode
SETDefault !4A -PAth CONNector
SETDefault !4A -PAth SwitchType
SETDefault !4A -PAth LineCoding
SETDefault !4A -PAth LineDistance = SH7
SETDefault !4A -PAth CLock
# Path-level path parameter configuration
# The following parameters may need to be changed from their default
# settings, based on your specific environment topology:
#
# LocalDialNo:
#
#
#
#
# (Note that the Rate Adaption path parameter is not applicable for
# for E1 PRI. All outbound calls attempt connection only at 64K.)
#
# Some examples on changing the LocalDialNo parameter setting are:
#
= E1_CRC4
= E1_Pri
= ETSI
= HDB3
= External
If you want outbound calls to provide a calling
phone number, you will need to set this parameter
for each path that will support outbound calls.
There is no default setting for this parameter.
Example Configuration Templates 145
