Port/Path Services
and Syntax
Connector Services
and Syntax for
Ultra-WAN Interfaces
Path and port parameters have their own dedicated service type
indicators, that are used in commands that change the setting of these
parameters.
Path parameters use the Path Service and port parameters use the Port
Service.
Table 12 lists the path and port numbering syntax rules that are used for
default naming for PathBuilder S5xx series switches.
Table 12 PathBuilder Path/Port Syntax Rules
Interface
LAN connectors
FlexWAN Serial
connectors
Ultra-WAN CSU/DSU
connectors*
T3/E3 connectors
ATM connectors
* The Ultra-WAN CSU/DSU interfaces on the model S590/S598/S599 PathBuilder switches
support multi-path ISDN PRI dial, as well as single-path leased unstructured operation.
Connector parameters do not have a dedicated service type indicator;
they use the Path Service type indicator. Table 13 lists the Ultra-WAN
connector syntax rules for the model S590/S598/S599 PathBuilder switch.
Table 13 PathBuilder S590 Connector Syntax Rules
Interface
Ultra-WAN CSU/DSU
Connectors
Path/Port
Syntax Syntax Description
<n> n = 1 or 2
<nm> n = 3 or 4
m = a, b, c, or d
<nm.p> n = 3 or 4
m = a, b, c, or d
p = 1, 2, ...30
<n> n = 3 or 4
<n> n = 3 or 4
Connector
Syntax Syntax Description
<4m> and m=a, b, c, or d
<3m>
