ADD !4A.11 -PA ChannelMap 11
ADD !4A.12 -PA ChannelMap 12
ADD !4A.13 -PA ChannelMap 13
ADD !4A.14 -PA ChannelMap 14
ADD !4A.15 -PA ChannelMap 15
ADD !4A.16 -PA ChannelMap 16
ADD !4A.17 -PA ChannelMap 17
ADD !4A.18 -PA ChannelMap 18
ADD !4A.19 -PA ChannelMap 19
ADD !4A.20 -PA ChannelMap 20
ADD !4A.21 -PA ChannelMap 21
ADD !4A.22 -PA ChannelMap 22
ADD !4A.23 -PA ChannelMap 23
ADD !4A.24 -PA ChannelMap 24
#
# ChannelBaud: This parameter specifies the baud rate (56K or 64K) of
# each timeslot (i.e. channel) mapped to the
# specified path.
# This setting can be changed to CB56K (56kbits/sec) for
# leased-line paths that require 56kbit/sec operation
#
# Some examples on changing the ChannelBaud parameter setting are:
#
# SETDefault !4A.1 -PAth ChannelBaud = CB56K
# SETDefault !4A.22 -PAth ChannelBaud = CB56K
# Enable Connector
SETDefault !4A -PAth ConnControl = Enable
Example 7.
########################################################################
########################################################################
# ULTRAWAN CONNECTOR CONFIGURATION FILE
# E1 LEASED, SINGLE PATH TEMPLATE
# HOW TO CONFIGURE MULTIPLE CONNECTORS SIMULTANEOUSLY
# This example shows how to configure connectors 4A, 4B, 4C, and 4D
# simultaneously by creating groups of connectors via the
# Instance Group command. To specify which connectors are
# included in this grouping, just add or delete the according references
# in the Instance Group command.
# 4A and 4C, the command would look like the following:
# Add -SYS InstanceGRoup E1FAT "!4A, !4C" PAth
# Add Instance Groups to cover all 4 UltraWAN connectors and paths
###### Note: E1FAT is short for E1, LEased, FAT (one) channel
Add -SYS InstanceGRoup E1FAT
Default setting is CB64K (64kbits/sec).
For example, to include only connectors
"!4A, !4B, !4C,
Example Configuration Templates
!4D" PAth
