# ULTRAWAN CONNECTOR CONFIGURATION FILE
# T1 PRI TEMPLATE
# HOW TO CONFIGURE A SINGLE CONNECTOR
# This example shows how to configure connector 4A. To configure
# connectors other than 4A, substitute the connector name, accordingly
# For example, to configure connector 4B, replace 4A with 4B
# in all of the commands shown below
# Connector-level path parameter configuration
# The following parameter settings are only typical example settings.
# Your network-specific settings need to be assigned by consulting the
# connector-level path parameter documentation in the document
# "Using the PathBuilder Switch"
SETDefault !4A -PAth FrameMode
SETDefault !4A -PAth CONNector
SETDefault !4A -PAth SwitchType
SETDefault !4A -PAth LineCoding
SETDefault !4A -PAth LineDistance = LH1
SETDefault !4A -PAth CLock
# Path-level path parameter configuration
# The following parameters may need to be changed from their default
# settings, based on your specific environment topology:
#
# LocalDialNo:
#
#
#
# Rate Adaption:
#
#
#
#
#
# Some examples on changing these parameter settings are:
#
# SETDefault !4A.1 -PAth LocalDialNo = "4085551212"
# SETDefault !4A.5 -PAth LocalDialNo = "4085551212"
# SETDefault !4A.23 -PAth LocalDialNo = "4085555555"
#
# SETDefault !4A.1 -PAth RateAdaption = "Rate56"
# SETDefault !4A.5 -PAth RateAdaption = "Rate56"
# SETDefault !4A.23 -PAth RateAdaption = "Rate56"
# ........
= T1_ESF
= T1_Pri
= ATT5ESS
= B8ZS
= External
If you want outbound calls to provide a calling
phone number, you will need to set this parameter
for each path that will support outbound calls.
There is no default setting for this parameter.
If you want outbound calls using a given path to
attempt connection only at one rate (56K or 64K),
but not both, then this parameter will need to be
changed from the default setting of AUTO (which,
if necessary, attempts both) to Rate56K, or Rate64K.
