ConnStatus

Syntax
SHow [!<path>] -PAth ConnStatus
The ConnStatus parameter displays the receive-side operational status of
Description
an Ultra-WAN CSU/DSU connector. The display is structured as follows:
CURRENT CONNECTOR 4.1 STATUS
--------------------------------------------------------
LED:
Carrier (Carrier Detect):GREEN (E1/T1 Frame Sync)
Alarm (Yellow/Blue Alarm):OFF (No Yellow or Blue Alarm Active)
Loopback (Any Loopback):Off (No Loopbacks Active)
---------------------------------------------------------
Layer1 Status:Loopback Status:
LOS (Loss of Signal): OFFRemote Payload: OFF
OOF (Red Alarm): OFFRemote Line:OFF
RAI (Yellow Alarm):OFF
AIS (Blue Alarm):OFF
The statistics definitions are as follows:
CD (Carrier Detect) LED: GREEN = None of ALOS, LOS, or RLOF active.
This LED is GREEN when frame synchronization to an E1 or T1 frame
pattern is present.
Alarm (Yellow Alarm) LED: SOLID YELLOW = RYEL, RMYEL, or RAIS. This
LED is YELLOW when the remote alarm indication bit (Yellow Alarm) is set
or when an AIS pattern is present on the received line signal.
Loopback (Any Loopback): SOLID YELLOW = PLOOP, LOOP, FLOOP, or
ALOOP. This LED is YELLOW when any type of loopback is in progress,
regardless of whether UI or CO switch initiated.
Remote Payload, Remote Line Loopbacks: ACTIVE when any of these
loopbacks is in progress.
LOS (Loss of Signal): ON = RALOS or RLOS. This status is ON when there is
no valid encoded signal present.
OOF (Red Alarm): ON = RLOF. This status is ON when a valid encoded
signal is present, but there is no frame synchronization to an E1 or T1
frame pattern.
