170 A I: C
PPENDIX OMMANDS AND

ConnConFig

Syntax
Description

ConnControl

Syntax
Default
Description

ConnCouNTers

Syntax
Description
P F U
ARAMETERS OR LTRA
SHow [!<path>] -PAth ConnConfig
The ConnConFig parameter displays the currently configured values for
all of the connector configuration parameters associated with the given
path. Note that since this display reflects the operational state of the
connector, no parameter setting changes made since the last time the
ConnControl parameter has explicitly been set to "Enable" will show in
this display.
A sample display is shown here:
Show !3b -Path ConnConFig
Path !3b FrameMode = T1_ESF
Path !3b CONNector = T1_Pri
Path !3b SwitchType = DMS100
Path !3b ENCoding = B8ZS
Path !3b LineDistance = LH1-0db
Path !3b CLock = External
Path !3b ConnControl = Enable
SETDefault !<path> -PAth ConnControl = ([Enabled | Disabled]
SHow !<path> -PAth ConnCONTrol
SHowDefault !<path> -PAth ConnControl
Disabled
The ConnControl parameter enables or disables the specified connector.
ConnControl must be explicitly set to Enabled (even if the parameter is
currently set to Enabled) to apply any connector configuration changes
made since ConnControl was last set to Enabled. A ConnControl setting
of Disabled disables all paths assigned to the specified connector, and
puts the transmitter in a T1 mode transmitting an AIS "all ones" signal.
ConnControl, when set to Disabled, disables all paths on the specified
connector.
SHow [!<path>] -PAth ConnCouNTers
The ConnCouNTers parameter displays statistics on the T1/E1 line. The
statistics are collected in 96 sample intervals (15 minute samples for the
-WAN CSU/DSU I
NTERFACES
