164 A H: C
PPENDIX OMPLETING
Example
Configuration
Templates
Example 1.
######################################################
#
# Ethernet LAN Emulation Configuration
# The configuration is for 2 elans defined for one path (3),
# and SCORE ATM routing between the two elans.
#
#######################################################
add !v1 -PORT VirtualPort 3 ethatm
add !v2 -PORT VirtualPort 3 ethatm
setd !v1 -ATMLE ElanName="elan50501_0"
setd !v2 -ATMLE ElanName="elan50501_1"
setd !v1 -IP NETaddr=198.18.1.1
setd !v2 -IP NETaddr=198.19.1.1
setd -IP CONTrol=ROute
setd !v1,!v2 -RIPip CONTrol=(TAlk,Listen)
Example 2.
######################################################
#
# TokenRing LAN Emulation Configuration
# The configuration is for 2 elans defined for one path (3),
# and SCORE ATM routing between the two elans.
#
#######################################################
add !v1 -PORT VirtualPort 3 tratm
add !v2 -PORT VirtualPort 3 tratm
setd !v1 -ATMLE ElanName="elan50501_2"
setd !v2 -ATMLE ElanName="elan50501_3"
setd !v1 -IP NETaddr=198.18.1.1
setd !v2 -IP NETaddr=198.19.1.1
setd -IP CONTrol=ro
setd !v1,!v2 -RIPip CONTrol=(TAlk,Listen)
setd -BRIDGE CONTrol=(NoAging,Bridge)
T ATM C
HE ONFIGURATION
