Note
The default IP address assigned
to the switch is 192.0.2.1. To
access the switch with the
default IP address, your work-
station must be on the 192.0.2.0
subnet.
Alternatively, you can connect to
the switch using Local Manage-
ment and set an IP address that
is on your network. Then you
can access the Web Device
Manager using the new IP
address.
32
4
Intel Express 460T Standalone Switch Users Guide
Accessing the Web Device Manager
1 In the Location or Address field of your Web browser type the IP
address of the switch. For example, to use the default IP address of the
switch, type 192.0.2.1 in the Location or Address field and then press
Enter.
2 When prompted, type your user name and password. By default, no
user name or password is assigned. If you set a user name and password
using Local Management, enter those here.
3 Click OK. The Web Device Manager screen appears in your Web
browser.
