50 Configuring a connection to the outside network
Configuring advanced WAN/ISP settings
Configuring advanced WAN/ISP settings
High availability
To edit a route entry
1
In the SGMI, in the left pane, click WAN/ISP.
2
On the Routing tab, under Static Routes, in the Route Entry drop-down list,
select a route entry.
3
Under Static Routes, change information in any of the fields.
4
Click Update.
To delete a route entry
1
In the SGMI, in the left pane, click WAN/ISP.
2
On the Routing tab, under Static Routes, in the Route Entry drop-down list,
select an entry.
3
Click Delete.
To view the routing list table
1
In the SGMI, in the left pane, click WAN/ISP.
2
On the Routing tab, scroll to the bottom of the page.
You can set advanced connectivity settings such as a DNS gateway, HA/LB,
SMTP binding, and failover. You can also set optional network settings, which
identify the appliance to a network.
Note: Model 320 appliances have one WAN port and do not support high
availability, load balancing, and bandwidth aggregation.
You can configure high availability for each WAN port in one of three ways:
Normal, Off, or Backup.
Table 3-4
High availability modes
Mode
Description
Normal
Load balancing settings apply to the port when it is enabled and
operational.
Off
WAN port is not used at all.
Table 3-4
describes each mode.
