LEDs generally only illuminate when the a compatible Symantec Gateway
Security WLAN Access Point option is inserted.
Figure 9-4 shows the rear panel on model 320. This graphic is for reference; the
full description of each feature is available in the Symantec Gateway Security
300 Series Installation Guide.
Figure 9-6 Model 320 rear panel
Figure 9-5 shows the rear panel of models 360 and 360R. This graphic is for
reference; the full description ofeach feature is available in the Symantec
Gateway Security 300 Series Installation Guide.
Figure 9-7 Model 360 and 360R rear panel
Table 9-2 describes each LED.
Table 9-2 LEDs
Location Symbol
1
Feature Description
Power Illuminates when the appliance is turned
on.
Logging, monitoring and updates
Interpreting LEDs
