170 Field descriptions
WAN/ISP field descriptions
Table C-13 Dial-up or ISDN tab field descriptions (Continued)
Section Field
Analog Status Port Status
Physical Link
PPP Link
PPP IP Address
Phone Line Speed Speed at which the modem is connected to the
Description
Describes the status of the serial port on the
security gateway where the modem is connected.
Possible port status includes:
Idle
■
Dialing
■
Internet Access
■
Hanging Up
■
Indicates whether the modem is connected to
the phone number.
Possible physical link status include:
Off
■
On
■
Possible PPP link status includes:
User Authenticated via PPP (User name/
■
password was correct)
Off
■
On
■
IP address that is assigned to your account when
you connect. If you have a static IP address, it is
the same each time. If the ISP assigns IP
addresses dynamically, the IP address may be
different each time a connection is established.
Possible PPP IP address values include:
0.0.0.0
■
IP from ISP
■
where IP from ISP is the IP address
dynamically allocated to you when you
connect.
ISP.
Possible phone line speeds include:
Unknown
■
#####
■
where ##### is a number representing the
phone speed. For example, 48800.
