2
3
To edit a route entry
1
2
3
4
To delete a route entry
1
2
3
To view the routing list table
1
2

Configuring advanced WAN/ISP settings

You can set advanced connectivity settings such as a DNS gateway, high availability/load balancing (HA/
LB), SMTP binding, and failover. You can also set optional network settings, which identify the appliance to
a network.
Note: Models 420 and 440 appliances have one WAN port, and do not support high availability, load
balancing, and bandwidth aggregation.

High availability

On dual-WAN port appliances, you can configure each WAN port to failover to the other in the case of line
connection failure.
You can configure high availability for each WAN port in one of three ways: Normal, Off, or Backup.
3-4 describes each mode.
Table 3-4
Mode
Normal
Off
On the Routing tab, under Static Routes, do the following:
Destination IP Type the IP address to which to send packets.
Netmask Type the net mask of the router to which to send packets.
Gateway Type the IP address of the interface to which packets are sent.
Interface Select the interface from which traffic is sent.
Metric Type a number to represent the order in which you want the entry evaluated. For example, to
evaluate the entry third, type 3.
Click Add.
In the SGMI, in the left pane, click WAN/ISP.
On the Routing tab, under Static Routes, in the Route Entry drop-down list, select a route entry.
Under Static Routes, change information in any of the fields.
Click Update.
In the SGMI, in the left pane, click WAN/ISP.
On the Routing tab, under Static Routes, in the Route Entry drop-down list, select an entry.
Click Delete.
In the SGMI, in the left pane, click WAN/ISP.
On the Routing tab, scroll to the bottom of the page.
High availability modes
Description
Load balancing settings apply to the port when it is enabled and operational.
WAN port is not used at all.
Configuring a connection to the outside network
Configuring advanced WAN/ISP settings
43
Table
