Symantec 360R - Security Gateway SGS Administration Manual page 92

92 Establishing secure VPN connections
Configuring Gateway-to-Gateway tunnels
succeed. If the key matches, then Security Parameter Index (SPI),
authentication, and encryption keys are automatically generated and the tunnel
is created. The security gateway usually re-keys (generates a new key)
automatically at set intervals to ensure the continued integrity of the key.
Configuration tasks for dynamic Gateway-to-Gateway
tunnels
Table 6-4 summarizes the tasks that are required to configure dynamic
Gateway-to-Gateway VPN tunnels.
Note: Complete each step in
and then for the remote security gateway.
Table 6-4 Dynamic Gateway-to-Gateway configuration tasks
Task
Configure a VPN Policy (Phase 2 IKE
negotiation).
(Optional)
Create a dynamic tunnel.
Define IPsec Security Association Parameters.
Select VPN Policy.
Define the local security gateway.
Define the remote security gateway.
Repeat the above steps for the remote security
gateway.
To add a dynamic Gateway-to-Gateway tunnel
See "Dynamic Tunnels tab field descriptions"
1 In the left pane, click VPN.
2 On the Dynamic Tunnels tab, in the Name text box, type a name for the new
tunnel.
3 To edit an existing tunnel, from the VPN Tunnel drop-down list, select a
VPN tunnel.
4 Check Enable VPN Tunnel.
Table 6-4 twice: first for the local security gateway
SGMI
VPN > VPN Policies
VPN > Dynamic Tunnels
VPN > Dynamic Tunnels > IPsec
Security Association
VPN > Dynamic Tunnels > Local
Security Gateway
VPN > Dynamic Tunnels > Remote
Security Gateway
on page 189.
