LAN IP & DHCP tab field descriptions
The LAN IP & DHCP tab lets you set the security gateway's IP address and
configure the security gateway to act as a DHCP server.
Table C-8 LAN IP & DHCP tab field descriptions
Section Field
LAN IP IP Address
Netmask
DHCP DHCP Server
Range Start IP
Address
Range End IP
Address
DHCP Table Host Name
IP Address
Physical
Address
Status
Description
IP address of the security gateway's internal interface.
The current IP address appears in the text boxes.
The default value is 192.168.0.1. You cannot set the
security gateway's IP address to 192.168.1.0.
Security gateway netmask. The current netmask
appears in the text boxes. The default value is
255.255.255.0.
Makes the security gateway act as a DHCP server. To
use another DHCP server, or if the clients use static IP
addresses, click Disable.
First IP address in the range of IP addresses that you
want the security gateway to assign to clients.
For example, if you want the security gateway to
assign IP addresses in the range 172.16.0.2 to
172.16.0.75, type 172.16.0.2 in the Range Start IP
Address text boxes.
Last IP address in the range of IP addresses that you
want the security gateway to assign to clients.
In the previous example, type 172.16.0.75 in the
Range End IP Address text boxes.
Name of the computer to which the security gateway
assigned an IP address.
IP address from the indicated range that the security
gateway assigned to the computer.
Physical (MAC) address of the network interface card
(NIC) in the computer that was assigned an IP address.
Status of the DHCP lease on the IP address that was
assigned to the computer.
Options are:
Leased
■
Reserved
■
