32 Configuring a connection to the outside network
Configuring connectivity
By default, all settings are associated with Session 1. For multi-session PPPoE
Accounts, configure each session individually. If you have multiple PPPoE
accounts, assign each one to a different session in the SGMI.
Before configuring the WAN ports to use a PPPoE account, gather the following
information:
User name and password
■
All PPPoE accounts require user names and passwords. Get this
information from your ISP before configuring PPPoE.
Static IP address
■
You may have purchased or are assigned a static IP address for the PPPoE
account.
To configure PPPoE
See "PPPoE tab field descriptions"
1 In the SGMI, in the left pane, click WAN/ISP.
2 For model 320, do the following:
In the right pane, on the Main Setup tab, under Connection Type, click
■
PPPoE (xDSL).
Click Save.
■
3
For model 360 or 360R, do the following:
In the right pane, on the Main Setup tab, under WAN1 (External), in the
■
Connection Type drop-down list, click PPPoE (xDSL).
To use WAN 2, under WAN 2 (External), under HA Mode, click Normal.
■
To use WAN2, under WAN2 (External), in the Connection Type drop-
■
down list, click PPPoE (xDSL).
Click Save.
■
In the right pane, on the PPPoE tab, in the right pane, on the PPPoE tab,
■
under WAN Port and Sessions, do one of the following:
On the WAN Port drop-down list, select a WAN port to configure.
■
4
If you have a multi-session PPPoE account, under WAN Port and Sessions,
on the PPPoE Session drop-down list, select the appropriate session.
5 If you have a single-session PPPoE account, leave the PPPoE session at
Session 1.
6 Under Connection, check Connect on Demand.
If you want to connect to a PPPoE session manually, uncheck Connect on
Demand, and then under Manual Control, click Connect.
on page 166.
