Symantec 360R - Security Gateway SGS Administration Manual page 37

2 For model 320, do the following:
In the right pane, on the Main Setup tab, under Connection Type, click
■
PPTP.
Click Save.
■
3
For model 360 or 360R, do the following:
Under WAN1 (External), in the Connection Type drop-down list, click
■
PPTP.
To use WAN 2, under WAN 2 (External), under HA Mode, click Normal.
■
To use WAN 2, under WAN2 (External), in the Connection Type drop-
■
down list, click PPTP.
Click Save.
■
4 In the right pane, on the PPTP tab, under Connection, check Connect on
Demand.
5 In the Idle Time-out text box, type the number of minutes of inactivity after
which you want the appliance to disconnect the PPTP connection.
6
In the Server IP Address text box, type the IP address of the PPTP server.
7 If you have a static IP PPTP Internet account, in the Static IP Address text
boxes, type the IP address.
Otherwise, leave the value at 0.
8 Under User Information, in the User Name text box, type your ISP account
user name.
9 In the Password text box, type your ISP account password.
10 In the Verify text box, type your ISP account password.
11 Click Save.
Verifying PPTP connectivity
Once the appliance is configured to use the PPTP account, verify that it connects
correctly.
To verify PPTP connectivity
See "PPTP tab field descriptions"
See "Status tab field descriptions"
1 In the SGMI, in the left pane, click WAN/ISP.
2 For model 320, in the right pane, on the PPTP tab, under Manual Control,
click Connect.
Configuring a connection to the outside network
on page 171.
on page 152.
Configuring connectivity
37
