Configuring Static Route Entries - Symantec 360R - Security Gateway SGS Administration Manual

Configuring static route entries

To enable dynamic routing
See "Routing tab field descriptions"
1 In the SGMI, in the left pane, click WAN/ISP.
2 On the Routing tab, under Dynamic Routing, check Enable RIP v2.
3 Click Save.
Before adding static routing entries to the routing table, gather the destination
IP, netmask, and gateway addresses for the router to which you want traffic to
be routed. Contact your IT department for this information.
You can add new route entries, edit existing entries, delete entries, or view a
table of entries.
Note: If NAT is enabled, only six routes display in Routing List. When NAT is
disabled, all configured routes appear in the list.
To configure static route entries
You can add, edit, or delete a static routing entry, or view the list of existing
entries.
See "Routing tab field descriptions"
To add a route entry
1 In the SGMI, in the left pane, click WAN/ISP.
2 On the Routing tab, under Static Routes, do the following:
Destination IP
Netmask
Gateway
Interface
Metric
3 Click Add.
Configuring a connection to the outside network
on page 174.
on page 174.
Type the IP address to which to send packets.
Type the net mask of the router to which to send packets.
Type the IP address of the interface to which packets are sent.
Select the interface from which traffic is sent.
Type a number to represent the order in which you want the
entry evaluated. For example to evaluate the entry third type
3.
49
Configuring routing
