Standard port assignment

When LAN ports are designated as standard, the appliance acts as a typical
switch: it forwards traffic based on MAC address and traffic does not reach the
security gateway engine unless it was specifically designated for it.
This option does not support client VPN tunnels terminating at the LAN. When a
LAN port is set to Standard, it is not considered part of the VLAN.
When you select Standard, VPN traffic is not enforced at the switch, that is, a
trusted private network is assumed.
To configure port assignments
You can set a specific LAN port to use a port assignment, or you can restore the
default port settings.
See "Port Assignment tab field descriptions"
To configure a port assignment
1 In the SGMI, in the left pane, click LAN.
2 In the right pane, on the Port Assignment tab, under Physical LAN Ports,
from the Port numbers drop-down list, select a port assignment.
3 Click Save.
The appliance reboots when the port settings are saved.
To restore port assignment default settings
1 In the SGMI, in the left pane, click LAN.
2 In the right pane, on the Port Assignment tab, under Physical LAN Ports,
click Restore Defaults.
The appliance reboots when the port settings are saved.
Configuring internal connections
Configuring port assignments
on page 162.
