Symantec 360R - Security Gateway SGS Administration Manual page 87

To configure users
See "Client Users tab field descriptions"
1 In the SGMI, in the left pane, click VPN.
2 In the right pane, on the Client Users tab, under VPN User Identity, in the
User Name text box, type the name of a new user.
3
To edit an existing user, in the User drop-down list, select a user.
4 Check Enable.
5 In the Pre-shared Key text box, type the pre-shared key.
6 From the VPN Group drop-down list, select a VPN group for the user to join.
7 Click Add.
To enable users with extended authentication
See "Advanced tab field descriptions"
1 In the SGMI, in the left pane, click VPN.
2 On the Advanced tab, in the Dynamic VPN Client Settings section, do the
following:
Check Enable Dynamic VPN Client Tunnels.
■
In the Pre-shared Key text box, type a key that your dynamic users will
■
enter in their client software.
3 In the RADIUS Settings section, do the following:
Primary RADIUS Server
Secondary RADIUS Server Type the IP address or fully qualified domain name of
Authentication Port (UDP) Type the port on the RADIUS server on which the
Shared Secret or Key
4 Click Save.
5 On the Client Tunnels tab, in the VPN Group drop-down list select the VPN
group to which the users that use extended authentication belong.
6 Under Extended User Authentication, do the following:
Check Enable Extended User Authentication.
■
Establishing secure VPN connections
on page 199.
on page 203.
Type the IP address or fully qualified domain name of
the RADIUS server.
the RADIUS server that the security gateway uses for
authentication should the primary server become
unavailable.
RADIUS service runs.
Type the RADIUS server key.
87
Identifying users
