6. Input the stitch length in 3 digits and press
If the value is "000", the stitch count remains unchanged. The stitch length increases or decreases.

Copying a pattern resized

Command to be used
This function is available only when the needle is at the home position.
The copied data is linked to the original data with a split data.
1. Make sure that the needle is at the home position.
Press if the n the needle is not at the home position.
2. Determine the reference point for resizing with
3. Input
4. Input the magnification in 3 digits in the X direction and press
Magnification values of 0 - 400 are available for input.
Copying a pattern resized in the X and Y directions
Used to input magnification in the X direction.
Used to input magnification in the Y direction.
.
.
.
Programmer
Chapter 3 Programming with Command Function
.
187
