Chapter 2 Programming with Help Function
Setting low-speed sewing
Carries out setting for low-speed sewing.
The following five options are available for low-speed sewing.
0 (Low-speed 0)
1 (Low-speed 1)
2 (Low-speed 2)
3 (Low-speed 3)
4 (Low-speed 4)
1.
Select
and press
2.
Select an option of low-speed sewing with
3.
Input the stitch count for sewing with the reduced maximum speed.
4.
Press
.
Low-speed sewing is carried out for the input stitch count.
104
Sewing speed is not reduced. (Used for canceling other options.)
The maximum sewing speed is set at 1200 rpm or lower.
The maximum sewing speed is set at 800 rpm or lower.
The maximum sewing speed is set at 600 rpm or lower.
The maximum sewing speed is set at 400 rpm or lower.
.
.
Input the desired stitch count.
Programmer
