12.2 Tramline rhythm

A tramline rhythm must be chosen. There are two possibiliies:
12.2.1 Uneven rhythm
The working width of the sprayer or fertiliser spreader may be 3, 5, 7, 9, 11,
13, 15,17, or 19 times wider with the LEMKEN Easytronic than the seed drill
width.
Example:
Sprayer Seed drill Tramline rhythm
12 metres 4 metres 3
The tramline rhythm in the example is 3. Tramlines are made when the actual
line is equal to the set tramline rhythm.
The lines are counted each time the drill is raised.
Observe when the lines need to be counted and especially when the lines
should not be counted.
See instruction book of the used seed drill control.
51
